| Accessories included | integrated Wall mount |
|---|---|
| Product | BCS-B-SIP154SR5L1 |
| Recording in BCS CLOUD | Yes |
| Sensor | 1/2.7'' CMOS |
| Lens | motozoom |
| Focus | Auto / manual |
| Active deterrence function ADC | Sound-optical alarm |
| Angle of view | H:104.1°~30.6° V:54.9°~17.4° D:108.3°~34.4° |
| WDR | 120dB |
| Ai - Built-in intelligent functions | Yes |
| Image rotate | Mirror, Flip 0°/90°/180°/270° |
| Camera type | PTZ |
| Resolution | 5 Mpx |
| Scanning system | Progressive Scan |
| Pixels | 2880(H)×1620(V) |
| Focal length | 2.8~12 mm |
| Aperture | F 1.6 |
| Iris | Auto |
| Optical zoom | 4× |
| Digital zoom | 16× |
| DORI | Detect 63~270m / Observe 25~108m / Recognize 13~54m / Identify 6~27m |
| Min illumination | 0.003Lux(F1.6,AGC) 0Lux(B/W,IR) |
| S/N ratio | 52dB |
| White balance | (AWB) Auto / manual |
| Backlight compensation | BLC / HLC / WDR(120dB) |
| Shutter | Auto / manual 1~1/100000s |
| Gain control | (AGC) Auto / manual |
| Noise reduction | 2D/3D DNR |
| Stream support | 3 |
| Resolutions | 5M(2880×1620) / 4M(2560×1440) / 3M(2304×1296) / 2M(1920×1080) / 720P(1280×720) / D1(720×576) / 2CIF(704×288) / (640×360) / CIF(352×288) |
| Main stream | 2880×1620 / 2560×1440 / 2304×1296 / 1920×1080 / 1280×720(25/30fps) |
| Second stream | 1280×720 / 720×576 / 704×288 / 640×360 / 352×288(25/30fps) |
| Third stream | 720×576 / 704×288 / 640×360 / 352×288(25/30fps) |
| Bitrate | 128Kbps~16Mbps |
| Video compression | H.265 / H.265+ / H.264 / H.264+ / MJPEG |
| Day/night | ICR mechanical infrared filter |
| Illuminator type | IR LED + WhiteLight |
| IR range | 50m |
| WhiteLight range | 10m |
| Microphone | Yes |
| Loudspeaker | Yes |
| Audio compression | G.711A / G.711U |
| Memory card slot | microSD 256GB |
| Support | Web Service, CMS BCS Manager (Windows/Linux/MAC), Mobile App(iOS, android) |
| Motion detect | 4 |
| Privacy masking | 4 |
| Network | RJ-45 10/100 Mbps |
| Compatibility | ONVIF(S/G/T) |
| Protocols | IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP , PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP , 802.1x , SNMP, SSL |
| Power supply | PoE |
| Power supply type | 12V DC / PoE(802.3af) |
| Power consumption | max 18W |
| Housing color | White |
| IP class | IP66 |
| Surge protection | TVS 2kV |
| Working environment | -20°C~+60°C max 95% RH |
| Dimensions | Ø133×269mm |
| Weight | 0.87 kg |
| PAN speed | 0.1°/s~50°/s(50°/s preset) |
| TILT speed | 0.1°/s~40°/s(40°/s preset) |
| PAN range | 0°~345° |
| TILT range | -10°~110° |
| Auto tracking | Yes |
| Ai - Perimeter protection | Yes |
Warning: This product belongs to the BCS BASIC product line.
Use only components and devices from the same line to ensure compatibility.
BCS BASIC
BCS-B-SIP154SR5L1
199,26 € gross
Out of Stock- 5Mpx pan-tilt IP camera
- ADC technology
- 1/2.7" PS CMOS sensor
- SkyLight technology
- 2.8–12 mm motorised zoom lens
- 4x optical zoom
- WDR 120dB
- IR 50m, WhiteLight 10m
- Microphone, speaker
- IP66-rated housing
- Built-in smart features
Out of stock
This product is out of stock right now. Leave your e-mail and we will let you know when it is back — or propose an equivalent.
