| Product | BCS-EA15FR3L3-G |
|---|---|
| pa_product-line | BCS UNIVERSAL |
| Camera type | Dome |
| Transmission standard | HD-CVI / AHD / HD-TVI / ANALOG CVBS |
| Resolution | 5 Mpx |
| Scanning system | Progressive Scan |
| Pixels | 2880(H)×1620(V) |
| Lens | fixed |
| Focal length | 2.8 mm |
| Aperture | F1.6 |
| Focus | fixed |
| Iris | fixed |
| Angle of view | H: 113.3° V: 62.1° D: 134.3° |
| DORI | Detect 59.8m / Observe 23.9m / Recognize 12m / Identify 6m |
| Min illumination | 0.05Lux(F1.6) 0.005Lux(B/W,F1.6,30IRE) 0Lux(B/W,IR) |
| S/N ratio | 65dB |
| White balance | (AWB) Auto / manual |
| WDR | DWDR |
| Backlight compensation | BLC / HLC / DWDR |
| Shutter | Auto / manual 1/30s~1/100000s |
| Gain control | (AGC) Auto / manual |
| Noise reduction | 3D DNR |
| Image rotate | Mirror |
| Resolutions | 5M(2880×1620) 4M(2560×1440) 1080p(1920×1080) 960H(960×576/960×480); TVI 5M 16:9(2960×1665) |
| Day/night | ICR mechanical infrared filter |
| Illuminator type | IR LED + WhiteLight |
| IR range | 30m |
| WhiteLight range | 30m |
| NightColor | Yes |
| Microphone | Yes |
| Support | Support for settings in the camera OSD menu by the BCS-XVR recorder |
| Privacy masking | 8 |
| Power supply | 12V DC |
| Power supply type | 12V DC |
| Power consumption | max 4.3W |
| Housing color | Graphite |
| IP class | IP67 |
| Working environment | – 40°~+60° max 95% RH |
| Dimensions | Ø94×85.7mm |
| Weight | 0.32 kg |
| Casing | Metal |
BCS-EA15FR3L3-G
57,81 € gross
100 In Stock- 5Mpx analogue HD dome camera
- HDCVI/AHD/TVI/CVBS
- PS CMOS sensor
- 2.8mm fixed lens
- IR 30m
- WhiteLight 30m
- Microphone
- IP67-rated housing
100 in stock
