| Spectral range | 8~14um |
|---|---|
| Product | BCS-L-EIP541FSR2-FDT(0401) |
| Camera type | Thermal |
| Scanning system | Progressive Scan |
| Focal length | 4 mm |
| Iris | fixed |
| White balance | (AWB) Auto / manual |
| Noise reduction | 2D/3D DNR |
| Temperature Measurement Range | 10m |
| Temperature measurement accuracy | Max (±5°C, ±5%) |
| Resolution | 4 Mpx |
| Sensor | 1/2.7'' CMOS |
| Second stream | 704×576/640×480/352×288@25fps |
| Pixels | 2688(H)×1520(V) |
| Lens | fixed |
| Aperture | F1.6 |
| Focus | fixed |
| Angle of view | H: 85° V: 44° D: 99° |
| Min illumination | 0.0052Lux 0.0028Lux(B/W) 0Lux(IR) |
| S/N ratio | 55dB |
| WDR | DWDR |
| Backlight compensation | BLC / HLC / DWDR |
| Shutter | Auto / manual 1~1/100000s |
| Gain control | (AGC) Auto / manual |
| Image rotate | Mirror, Flip 180° , tryb korytarzowy (90°/270°) |
| Stream support | 2 |
| Resolutions | 4M(2688×1520) / 2M(1920×1080) / 1.3M(1280×960) / 720P(1280×720) / D1(704×576) / VGA(640×480) / CIF(352×288) |
| Main stream | 2688×1520/1920×1080/1280×960/1280×720@25fps |
| Video compression | H.265 / H.264 / H.264H / H.264B / MJPEG |
| Day/night | ICR |
| Illuminator type | IR LED |
| IR range | 20m |
| Microphone | Yes |
| Loudspeaker | Yes |
| Audio compression | G.711a / G.711mu / AAC / PCM / MP2L2 / G.726 |
| Alarm in | 1 |
| Alarm out | 1 |
| Storage | FTP / SFTP / NAS |
| Support | Web Service, CMS BCS Manager (Windows/Linux/MAC), Mobile App(iOS, android) |
| Privacy masking | 4 |
| Network | RJ-45 10/100 Mbps |
| Compatibility | ONVIF |
| Protocols | HTTPS, HTTP, TCP, ARP, RTSP, RTP, UDP, RTCP, SMTP, FTP, DHCP, DNS, DDNS, PPPOE, IPv4/v6, SNMP, QoS, UPnP, NTP |
| Network security | Authorized username and password, attached MAC address, encrypted HTTPS, IEEE 802.1x, controlled network access |
| Power supply | PoE |
| Power supply type | 12V DC / PoE(802.3af) |
| Housing color | White |
| IP class | IP66 |
| Working environment | -10°C~+55°C max 95% RH |
| Dimensions | Ø106×94mm |
| Weight | 0.35 kg |
| Casing | Metal |
| Thermal camera sensor | Focal plane detector microbolometric sensor with active absorbing material Vox |
| Thermal camera resolution | 120(H)×90(V) |
| Thermal camera lens | 1.2 mm |
| Thermal camera aperture | F1.1 |
| Thermal camera angle of view | H: 90° V: 67.5° |
| Temperature measurement | Yes |
| Fire detection distance | 10m |
| Fire detection and alarm | Yes |
| Pixel size | 17um |
| Thermal sensitivity | 60mK |
Warning: This product belongs to the BCS LINE product line.
Use only components and devices from the same line to ensure compatibility.
BCS LINE
BCS-L-EIP541FSR2-FDT(0401)
423,12 € gross
22 In Stock- Dual-sensor thermal and visual camera
- Radiometric technology
- Designed for fire and flame detection
- Recommended detection range: 10 m
- 120 (H) × 90 (V) pixels
- Thermal lens: 1.2 mm
- Temperature measurement: -10°C to +200°C max (±5°C, ±5%)
- 4Mpx video camera with a 1/2.7'' sensor and a 4mm lens
- Infrared illuminator: 20 m
- Built-in microphone and speaker
- 70dB audible alarm
- Alarm input and output
- IP66-rated housing
