BCS Line 8-channel IP recorder. Adapted to work with cameras with a maximum resolution of 4Mpx. Number of channels: 8 to 4Mpx, Technology: IP, Video compression: H.265 / H.264 / MJPEG, Video inputs / outputs: 1x VGA, 1x HDMI, 2x TV, Other connectors: 3x USB 2.0, Audio In / Out, 9 alarm inputs, 2 alarm outputs, 3x RS232, 2x RS485, Archiving: 2x HDD SATA (max. 6TB per disk), 3x USB, Network interface: 1x RJ-45 port (10/100 / 1000M), Built-in PoE switch: 8 ports, Built-in 4G and GPS module, Incoming bitrate: 80Mbps, Power supply: DC 6V-36V.
Warning: This product belongs to the BCS LINE product line.
Use only components and devices from the same line to ensure compatibility.
BCS LINE
BCS-L-MNVR0802-A-8P-4G
0,00 € gross
Out of Stock- 8-channel mobile IP recorder
- Built-in 4G and GPS module
- Built-in 8-port PoE switch
- Supports 2 x 2.5-inch hard drives
- Supports 4Mpx IP cameras
- 9/2 alarm, 1/1 audio
- HDMI/VGA output
- Power supply: 6–36 V DC
This product is out of stock right now. Leave your e-mail and we will let you know when it is back — or propose an equivalent.
| Weight (without HDD) | 2.05 kg |
|---|---|
| Product | BCS-L-MNVR0802-A-8P-4G |
| System | IP |
| Channels | 8 |
| Max recording resolution | 4 Mpx |
| Power consumption (without HDD) | max 11.1 |
| VGA out | VGA |
| Flag | TO ORDER |
| Pentaplex function | Live view / recording / playback / archiving / remote access |
| HDD support | 2 |
| HDD capacity | 2 TB |
| Recording resolutions | 4M / 3M / 2M / 1.3M / 720P / D1 |
| Video compression | H.265+ / H265 / H.264+ / H.264 |
| HDMI out | HDMI |
| BNC out | 2×BNC |
| HDMI display resolutions | 1920×1080 / 1280×1024 / 1280×720 / 1024×768 |
| VGA display resolutions | 1920×1080 / 1280×1024 / 1280×720 / 1024×768 |
| Display split | 1/4/8/9 |
| Synchronous playback | 1/4/9 |
| Archiving | Possibility to download material to external media such as USB FLASH, USB HDD |
| Interfaces | 3×USB2.0, 4G module, GPS module, SIM card slot, 256GB SD card slot |
| Serial port | 3×RS232, 2×RS485 |
| Audio in | 1 |
| Audio out | 1 |
| Alarm in | 9 |
| Alarm out | 2 |
| Support | Local, Web Service, CMS BCS Manager (Windows/Linux/MAC), Mobile App(iOS, android) |
| Network | RJ-45 10/100/1000Mbps |
| Compatibility | ONVIF, support third party cameras |
| PoE channels | 8 |
| Power supply | 6~36V DC |
| Working environment | -30°C~+70°C max 90% RH |
| Casing | mobile |
| Dimensions (W×D×H) | 180×190×50mm |
