16-channel, 2-disk IP recorder from BCS Line series. H.265 + / H265 / H.264 + / H.264 compression, HDMI output (3840 × 2160), VGA (1920 × 1080), P2P support (cloud), built-in intelligent functions. Archiving: 2x HDD (up to 10TB each), 1 interfaces × USB2.0, 1xUSB3.0, RS485, RS232, Audio input and output, Power supply: 100 ~ 240V AC.
Warning: This product belongs to the BCS LINE product line.
Use only components and devices from the same line to ensure compatibility.
Save 71%
BCS LINE
BCS-L-NVR1602-A-4K-16P-Ai
668,09 € gross
16 In Stock- 16-channel IP recorder
- Built-in 16-port 130W PoE switch
- Supports 2 hard drives
- Supports 24Mpx IP cameras
- 4/2 alarm, 1/1 audio
- HDMI 4K/VGA output
- Built-in smart features
16 in stock
- DPD across Europe & worldwide — free in the EU from 1000,00 € (ex. VAT)
- Official BCS e-commerce Business Partner
- Technical support
| Power consumption (without HDD) | max 15.6W |
|---|---|
| &Ai - Built-in intelligent functions | Yes |
| Ai - Intelligent functions from recorder | Facial identification, metadata, perimeter protection (person/vehicle recognition), SMD Plus |
| Ai - Intelligent functions from camera | ARTR |
| Ai - SMD - Smart Motion Detection | 12 channels from recorder |
| Flag | OUTLET |
| Product | BCS-L-NVR1602-A-4K-16P-Ai |
| System | IP |
| Pentaplex function | Live view / recording / playback / archiving / remote access |
| Channels | 16 |
| HDD support | 2 |
| HDD capacity | 10 TB |
| Max recording resolution | 24 Mpx |
| Incoming bandwidth | 320Mbps(160Mbps Ai) |
| Outgoing bandwidth | 320Mbps(160Mbps Ai) |
| Display efficiency | 4×8M@30fps /16×2M@30fps |
| Recording resolutions | 24M / 16M / 12M / 8M / 6M / 5M / 4M / 3M / 2M / 1.3M / 720P / D1 |
| Video compression | H.265+ / H265 / H.264+ / H.264 / MJPEG |
| HDMI out | HDMI4K |
| VGA out | VGA |
| HDMI display resolutions | 3840×2160 / 1920×1080 / 1280×1024 / 1280×720 / 1024×768 |
| VGA display resolutions | 1920×1080 / 1280×1024 / 1280×720 / 1024×768 |
| Display split | 1/4/8/9/16 |
| Synchronous playback | 1/4/9/16 |
| Archiving | Possibility to download material to external media such as USB FLASH, USB HDD |
| User connections | 128 |
| Interfaces | 1×USB2.0, 1×USB3.0 |
| Serial port | RS232, RS485 |
| Audio in | 1 |
| Audio out | 1 |
| Audio compression | G.711A / G.711U / G.726 / AAC / PCM |
| Alarm in | 4 |
| Alarm out | 2 |
| Support | Local, Web Service, CMS BCS Manager (Windows/Linux/MAC), Mobile App(iOS, android) |
| Network | RJ-45 10/100/1000Mbps |
| Compatibility | ONVIF, support third party cameras |
| Protocols | HTTP, HTTPS, TCP/IP, IPv4/IPv6, UPnP, SNMP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, DDNS, FTP, Alarm Server, IP Search |
| Standard | IEEE 802.3 af/at |
| Switch PoE power | 130W max 25.5W/port |
| PoE channels | 16 |
| ePoE & EoC | Port 1~8 |
| Power supply | 100~240V AC |
| Working environment | -10°C~+55°C max 90% RH |
| Casing | 1U |
| Dimensions (W×D×H) | 375×327.4×53.8mm |
| Weight (without HDD) | 2.7 kg |
| POS | Posnet |
| Ai - Perimeter protection | 12 channels from the recorder, 10 rules per channel |
| &Ai - Object classification | Yes |
| &Ai - SMD | Yes |
| Ai - Face recognition | 4 channels of identification from the recorder / 16 channels of identification from the recorder with a camera for face detection (16 images/s) / up to 20 face databases, 200 thousand images |
| Ai - Metadata | Person attributes, motor vehicle attributes |
| Ai - Smart search | AcuPick technology – intelligent search for human/vehicle objects in the recording history with camera with the AcuPick function |
