| Ai - ARTR | 8 channels from camera / black and white list 20k records |
|---|---|
| Power consumption (without HDD) | max. 10W |
| &Ai - Built-in intelligent functions | Yes |
| Ai - Intelligent functions from recorder | Face detection, face recognition, perimeter protection (human/vehicle classification), SMD Plus |
| Ai - Intelligent functions from camera | Face detection, face identification, metadata (human/vehicle classification), perimeter protection, SMD Plus, people gathering, people counting, ARTR, vehicle density, heat map |
| Ai - SMD - Smart Motion Detection | 8 channels from nvr / 16 channels from camera |
| Product | BCS-L-NVR1602-A-4K-16P |
| System | IP |
| Pentaplex function | Live view / recording / playback / archiving / remote access |
| Channels | 16 |
| HDD support | 2 |
| HDD capacity | 20 TB |
| ANR | Automatic Network Replenishment |
| Max recording resolution | 32 Mpx |
| Incoming bandwidth | 384Mbps(200Mbps Ai) |
| Outgoing bandwidth | 384Mbps(200Mbps Ai) |
| Display efficiency | 2×32M@20fps /2×24M@20fps /4×16M@30fps /5×12M@30fps /8×8M@30fps /12×5M@30fps /16×4M@30fps /1×32M Ai@20fps /1×24M Ai@20fps /2×16M Ai@30fps /4×12M Ai@30fps /4×8M Ai@30fps /8×5M Ai@30fps /12×4M Ai@30fps |
| Recording resolutions | 32M / 24M / 16M / 12M / 8M / 5M / 4M / 2M / 1.3M / 720P / D1 |
| Video compression | H.265+ / H265 / H.264+ / H.264 / MJPEG |
| HDMI out | HDMI4K |
| VGA out | VGA |
| HDMI display resolutions | 3840×2160 / 1920×1080 / 1280×1024 / 1280×720 / 1024×768 |
| VGA display resolutions | 1920×1080 / 1280×1024 / 1280×720 / 1024×768 |
| Display split | 1/4/8/9/16 |
| Synchronous playback | 1/4/9/16 |
| Archiving | Possibility to download material to external media such as USB FLASH, USB HDD |
| User connections | 128 |
| Interfaces | 1×USB2.0, 1×USB3.0 |
| Serial port | RS232, RS485 |
| Audio in | 1 |
| Audio out | 1 |
| Audio compression | G.711A / G.711U / G.726 / PCM |
| Alarm in | 4 |
| Alarm out | 2 |
| Support | Local, Web Service, CMS BCS Manager (Windows/Linux/MAC), Mobile App(iOS, android) |
| Network | RJ-45 10/100/1000Mbps |
| Compatibility | ONVIF(S/G/T), support third party cameras |
| Protocols | HTTP, HTTPS, TCP/IP, IPv4/IPv6, RTSP, UDP, SNMP, NTP, DHCP, DNS, SMTP, UPnP, IP Filter, PPPoE, FTP, DDNS, Alarm Server, IP Search, Multicast, P2P, Auto Registration |
| Standard | IEEE 802.3 af/at |
| Switch PoE power | 130W max 25.5W/port |
| PoE channels | 16 |
| ePoE & EoC | Port 1~8 |
| Power supply | 100~240V AC |
| Working environment | -10°C~+55°C max 93% RH |
| Casing | 1U |
| Dimensions (W×D×H) | 375×328×53mm |
| Weight (without HDD) | 2.7 kg |
| POS | Posnet |
| Ai - Perimeter protection | 4 channels from nvr, 10 rules for channel / 16 channels from camera |
| &Ai - Object classification | Yes |
| Ai - Face detection | 2 channels from nvr (12 images/s) / 16 channels from camera / face attributes (gender, age, glasses, expression, mask, beard) |
| &Ai - SMD | Yes |
| Ai - Smart search | AcuPick technology – intelligent search for human/vehicle objects in the recording history with camera with the AcuPick function |
| Ai - Metadata | 8 channels from camera / people attributes (top color, top type, hat, bag, age, gender, umbrella) / vehicle attributes (license plate, plate color, vehicle type, logo, calling, passengers, helmet) |
Warning: This product belongs to the BCS LINE product line.
Use only components and devices from the same line to ensure compatibility.
BCS LINE
BCS-L-NVR1602-A-4K-16P
1463,70 € gross
Out of Stock- 16-channel IP recorder
- AcuPick technology
- exPoE technology
- Built-in 16-port 130W PoE switch
- Support for 2 hard drives
- Supports 32Mpx IP cameras
- 4/2 alarm, 1/1 audio
- HDMI 4K/VGA output
- Built-in smart features
Out of stock
This product is out of stock right now. Leave your e-mail and we will let you know when it is back — or propose an equivalent.
