Name: BCS-L-NVR3204-A-8K-AI3/PRO
SKU: 13302
Price: 2697.39 EUR
Availability: InStock

Product

BCS-L-NVR3204-A-8K-AI3/PRO

pa_product-line

BCS LINE

System

IP

Pentaplex function

Live view / recording / playback / archiving / remote access

Channels

32

HDD support

4

HDD capacity

20 TB

Record mode

Continuous, manual, alarm, motion detection, schedule, Ai

Max recording resolution

32 Mpx

Incoming bandwidth

512Mbps(200Mbps Ai)

Outgoing bandwidth

384Mbps(200Mbps Ai)

Recording bandwidth

512Mbps(200Mbps Ai)

Display efficiency

2×32M@30fps /3×24M@30fps /5×16M@30fps /6×12M@30fps /10×8M@30fps /13×6M@30fps /16×5M@30fps /20×4M@30fps /32×2M@30fps Ai: 1×32M@30fps /1×24M@30fps /2×16M@30fps /4×12M@30fps /6×8M@30fps /8×6M@30fps /8×5M@30fps /12×4M@30fps /24×2M@30fps / 32×720P@30fps

Recording resolutions

32M / 24M / 16M / 12M / 8M / 6M / 5M / 4M / 3M / 2M / 1.3M / 720P / D1 / CIF / QCIF

Video compression

H.265+ / H265 / H.264+ / H.264 / MJPEG

HDMI out

2×HDMI8K

VGA out

2×VGA

HDMI display resolutions

7680×4320 / 3840×2160 / 1920×1080 / 1280×1024 / 1280×720

VGA display resolutions

1920×1080 / 1280×1024 / 1280×720

Display split

Main screen: 1/4/8/9/16/25/36 Secondary screen: 1/4/8/9/16

Recording

continuous recording, with motion detection (with recording before and after detection), alarm (with pre- and post-alarm recording), cyclic (overwriting), Ai

Synchronous playback

1/4/9/16

Archiving

Possibility to download material to external media such as USB FLASH, USB HDD

User connections

128

Interfaces

1×USB2.0, 2×USB3.0, eSATA

Serial port

RS232, RS485

Audio in

1

Audio out

2

Audio compression

G.711A / G.711U / G.726 / PCM

Alarm in

16

Alarm out

6

Alarm

Motion detection, signal lost,, sabotage, scene change, PIR, IPC, Ai functions, offline, HDD, IP, MAC, login

Support

Local, Web Service, CMS BCS Manager (Windows/Linux/MAC), Mobile App(iOS, android)

Network

2×RJ-45 10/100/1000Mbps

Compatibility

ONVIF(S/G/T/M), support for cameras from other manufacturers

PTZ control

Inteligent 3D positioning with PTZ cameras BCS LINE series.

Protocols

HTTP, HTTPS, TCP/IP, IPv4, IPv6, UDP, NTP, DHCP, DNS, SMTP, UPnP, IP Filter, FTP, DDNS, SNMP, Alarm Server, P2P, Auto Registration, IP Search, ISCSI

Power supply

100~240V AC

pa_power-consumption-without

max 18W

Working environment

-10°C~+55°C max 93% RH

Casing

1.5U

pa_dimensions-mm-wxdxh

440×411.5×76

Weight (without HDD)

4.37 kg

POS

Posnet

pa_ai-built-in-intelligent-f

Yes

Ai - Perimeter protection

16 channels from the recorder, 10 rules per channel / 32 channels from cameras

&Ai - Object classification

Yes

Ai - Face detection

16 channels of DVR, 12 images per second per channel / Xinghan Large-Scale AI Models: 8 channels of DVR, 12 images per second per channel / 32 channels of cameras

&Ai - SMD

Yes

Ai - Face recognition

32 detections from camera + identification from recorder 32 images/s / 16 detections from recorder + identification from recorder 16 images/s / Xinghan Large-Scale AI Model: 8 detections from recorder + identification from recorder 16 images/s

Ai - Metadata

16 DVR channels / Xinghan Large-Scale AI Model: 8 DVR channels / 32 camera channels / 23 attributes

Ai - Smart search

AcuPick technology – intelligent search for human/vehicle objects in the recording history with camera with the AcuPick function

pa_ai-large-scale-models

Enhanced AI analysis with improved accuracy and efficiency on a limited number of channels

pa_ai-intelligent-functions-

Face detection, face identification, metadata (person/vehicle recognition), perimeter protection, SMD, crowd detection, people counting, ARTR, vehicle traffic density, object monitoring, heat map

Ai - ARTR

32 channels from nvr / black and white list 20k records

pa_ai-smd-smart-motion-detec

32 channels from the recorder / 32 channels from the cameras

Accessories included

Rack mounts, mouse, IEC C13 power cable, RJ45 cable, hard drive power cable, SATA hard drive cable
