Name: BCS-L-SIP8245SR55-Ai2
SKU: 11637
Availability: OutOfStock

BCS-L-SIP8245SR55-Ai2

0,00 € gross

Out of Stock

2Mpx pan-tilt IP camera
1/2.8" STARVIS PS CMOS sensor
SkyLight technology
3.95–177.7 mm motorised zoom lens
45x optical zoom
WDR 120dB
IR laser 550m
Alarm 7/2, audio 1/1
IP67-rated housing
Built-in smart features

This product is out of stock right now. Leave your e-mail and we will let you know when it is back — or propose an equivalent.

Accessories included	Wall mount, adapter APTZ2, power supply 36VDC
Flag	TO ORDER
Sensor	1/2.8'' CMOS STARVIS
RAM	1GB
Focal length	3.95~177.7 mm
Optical zoom	45×
S/N ratio	55dB
Gain control	(AGC) Auto / manual
Ai - Built-in intelligent functions	Built-in intelligent algorithm of image analisis
Ai - SMD - Smart Motion Detection	SMD 4.0
Stream support	3
Product	BCS-L-SIP8245SR55-Ai2
Camera type	PTZ
Resolution	2 Mpx
Scanning system	Progressive Scan
Pixels	1920(H)×1080(V)
ROM	4GB
Lens	motozoom
Aperture	F 1.6~4.95
Focus	Auto / manual
Iris	Auto / manual
Digital zoom	16×
Angle of view	H:68°~2.3° V:41.7°~1.2° D:75.1°~2.4°
DORI	Detect 2452m / Observe 968m / Recognize 490m / Identify 245m
Min illumination	0.005Lux(Color,F1.6) 0.0005Lux(F1.6,B/W) 0Lux(B/W,IR)
White balance	(AWB) Auto / manual
WDR	120dB
Backlight compensation	BLC / HLC / WDR(120dB)
Shutter	Auto / manual 1~1/30000s
Noise reduction	2D/3D DNR
Image Stabilization	Electronic (EIS)
Defog	Electronic
Image rotate	Flip 180°
Resolutions	2M(1920×1080) / 1.3M(1280×960) / 720P(1280×720) / VGA(640×480) / D1(704×576/704×480) / CIF(352×288/352×240)
Main stream	1920×1080 / 1280×960 / 1280×720(50/60fps)
Second stream	704×576 / 704×480 / 640×480 / 352×288 / 352×240(25/30fps)
Third stream	1920×1080 / 1280×960 / 1280×720 / 704×576 / 704×480 / 352×288 / 352×240(25/30fps)
Bitrate	H264: 184 Kbps~9472 Kbps H265: 73 Kbps~5632 Kbps
Video compression	H.265 / H.265+ / H.264+ / H.264 / MJPEG
Day/night	ICR mechanical infrared filter
Illuminator type	Laser
IR range	550m
Audio in	1
Audio out	1
Audio compression	G.711A / G.711Mu / G.726 / AAC / G.722 / G.729 / MPEG2-L2
Alarm in	7
Alarm out	2
Storage	FTP, SFTP, NAS
Memory card slot	microSD 512GB
Other interfaces	RS485
Support	Web Service, CMS BCS Manager (Windows/Linux/MAC), Mobile App(iOS, android)
Motion detect	4
Privacy masking	24
Network	RJ-45 10/100 Mbps
Compatibility	ONVIF(S/G/T)
Protocols	FTP, RTMP, IPv6, Bonjour, IPv4, DNS, RTCP, PPPoE, NTP, RTP, 802.1x, HTTPS, SNMP, TCP/IP, DDNS, UPnP, NFS, ICMP, UDP, IGMP, HTTP, SSL, DHCP, SMTP, Qos, RTSP, ARP
Power supply	PoE
Power supply type	36V DC / PoE(802.3bt)
Power consumption	max 45W
Housing color	White
IP class	IP67
Surge protection	TVS 6kV
Working environment	-40°C~+70°C max 95% RH
Dimensions	Ø240mm×382mm
Weight	6.8 kg
PAN speed	0.1°/s~200°/s(240°/s preset)
TILT speed	0.1°/s~120°/s(200°/s preset)
PAN range	0°~360°
TILT range	-20°~90° auto-flip
Auto tracking	Yes
Automatic functions	300 presets, 8 tour(32 presety), 5 pattern, 5 auto scan
Ai - Perimeter protection	Intrusion, crossline, fast moving, loitering, people gathering, parking detection
&Ai - Object classification	Yes
Ai - Face detection	Face detection and tracking, snapshot, attributes and expression recognition
&Ai - SMD	Yes
Ai - Metadata	People attributes (gender, clothes, color, bag, hat, umbrella), face attributes (gender, age, expression, glasses, mask, beard), vehicle attributes (type, color, logo, seat belts, smoking, calling)
Ai - Human/vehicle detection	Human/vehicle classification for crossline and intrusion and fast moving reduces false alarms
