| Ai - ARTR | |
|---|---|
| Resolution | 4 Mpx |
| Scanning system | Progressive Scan |
| ROM | 4GB |
| Focus | Auto / manual |
| Angle of view | H: 92°~46.1° V: 49°~26° D: 109°~52.8° |
| White balance | (AWB) Auto / manual |
| Ai - Built-in intelligent functions | Built-in intelligent algorithm of image analisis |
| Product | BCS-L-TIP74VSR3-ITC-Ai3 |
| Camera type | Bullet |
| Sensor | 1/1.8'' CMOS |
| Pixels | 2688(H)×1520(V) |
| RAM | 1GB |
| Lens | motozoom |
| Focal length | 2.7~12 mm |
| Aperture | F1.4 |
| Iris | Auto |
| Optical zoom | 4× |
| Digital zoom | 16× |
| DORI | Detect 60~129m / Observe 24~52m / Recognize 12~26m / Identify 6~13m |
| Min illumination | 0.001Lux(Color,F1.4,30IRE) 0.0002Lux(F1.4,B/W,30IRE) 0Lux(IR) |
| S/N ratio | 56dB |
| Noise reduction | 3D DNR |
| WDR | 140dB |
| Backlight compensation | BLC / HLC / WDR(140dB) / SSA |
| Shutter | Auto / manual 1/25~1/100000s |
| Gain control | (AGC) Auto / manual |
| Stream support | 2 |
| Resolutions | 4M(2688×1520) /2M(1920×1080) /720P(1280×720) /960H(960×576/960×480) /D1(704×576/704×480) /CIF(352×288/352×240) |
| Main stream | 2688×1520(1~25/30fps) 1920×1080(1~25/30fps) 1280×720(1~25/30fps) |
| Second stream | 1280×720(1~25/30fps) 960×576(1~25fps) 960×480(1~30fps) 704×576(1~25fps) 704×480(1~30fps) 352×288(1~25fps) 352×240(1~30fps) |
| Bitrate | H.264B: 2,179 kbps–13,074 kbps H.264M: 2,179 kbps–13,074 kbps H.264H: 2,179 kbps–13,074 kbps H.265: 2,179 kbps–13,074 kbps MJPEG: 6,537 kbps–39,223 kbps |
| Video compression | H.265, H.264H, H.264B, H.264M, MJPEG |
| Day/night | ICR mechanical infrared filter |
| Illuminator type | IR LED |
| IR range | 30m |
| Microphone | Yes |
| Loudspeaker | Yes |
| Audio out | 1 |
| Alarm in | 2 |
| Alarm out | 2 |
| Memory card slot | microSD 256GB |
| Other interfaces | RS485, Wiegand SHA-1 26 bit |
| Support | Web Service, CMS BCS Manager (Windows/Linux/MAC), Mobile App(iOS, android) |
| Network | RJ-45 10/100/1000 Mbps |
| Compatibility | ONVIF(S/G/T) |
| Protocols | HTTP, Https, 802.1x, TCP, ARP, RTSP, RTP, UDP, RTCP, SMTP, FTP, DHCP, DNS, IPv4/v6, NTP, SFTP,DDNS, SNMP, PPPoE |
| Network security | |
| Power supply | PoE |
| Power supply type | 12V DC / PoE(802.3at) |
| Power consumption | max 20W |
| Housing color | Graphite |
| IP class | IP67 |
| IK10 | Yes |
| Working environment | -40°C~+70°C max 95% RH |
| Dimensions | 396×120.8×127.8mm |
| Weight | 2.3 kg |
Warning: This product belongs to the BCS LINE product line.
Use only components and devices from the same line to ensure compatibility.
BCS LINE
BCS-L-TIP74VSR3-ITC-Ai3
1584,24 € gross
Out of Stock- 4Mpx IP bullet camera
- ARTR for reading number plates
- 1/1.8" PS CMOS sensor
- SkyLight technology
- 2.7–12 mm motorised zoom lens
- WDR 140dB
- IR 30m
- Alarm 2/2, audio, microphone, speaker
- IP67, IK10 housing
- Built-in smart features
Out of stock
This product is out of stock right now. Leave your e-mail and we will let you know when it is back — or propose an equivalent.
