| Ai - Human/vehicle detection | Recognition of people entering the area and crossing the line reduces false alarms. |
|---|---|
| Camera type | Dome |
| Sensor | 1/1.8'' CMOS |
| Lens | fixed |
| Iris | fixed |
| Min illumination | 0.0003Lux(F1.0,AGC) |
| Backlight compensation | BLC / HLC / WDR(120dB) |
| Ai - Built-in intelligent functions | Built-in intelligent algorithm of image analisis |
| Product | BCS-P-EIP26FCL3-Ai1 |
| NDAA | National Defense Authorization Act |
| Resolution | 6 Mpx |
| Scanning system | Progressive Scan |
| Pixels | 3072(H)×2048(V) |
| Focal length | 2.8 mm |
| Aperture | F1.0 |
| Focus | fixed |
| Defog | Digital |
| Digital zoom | 16× |
| Angle of view | H: 110.4°, V: 60.5° D: 115.2° |
| DORI | Detect 43m / Observe 17m / Recognize 9m / Identify 4m |
| S/N ratio | 52dB |
| White balance | (AWB) Auto / manual |
| WDR | 120dB |
| Shutter | Auto / manual 1~1/100000s |
| Gain control | (AGC) Auto / manual |
| Noise reduction | 2D/3D DNR |
| RoI | Region of Interest |
| Image rotate | Mirror, Flip 0°/90°(corridor mode)/180°/270° |
| Stream support | 2 |
| Resolutions | 6M(3072×2048) / 4M(2688×1520)(2560×1440) / 3M(2304×1296) / 2M(1920×1080) / 720P(1280×720) / D1(720×576) / (640×360) / 2CIF(704×288) / CIF(352×288) |
| Main stream | 3072×2048@25fps 2688×1520@25fps 2560×1440@25fps 2304×1296@30fps 1920×1080@30fps |
| Second stream | 1280×720@30fps 720×576@30fps 640×360@30fps 704×288@30fps 352×288@30fps |
| Bitrate | 128Kbps~6144kbps |
| Video compression | H.265 / H.265+ / H.264 / MJPEG |
| Illuminator type | WhiteLight |
| WhiteLight range | 30m |
| NightColor | NightColor 2.0 |
| Microphone | Yes |
| Audio compression | G.711A / G.711U |
| Storage | NAS(NFS) |
| Memory card slot | microSD 512GB |
| Support | Web Service, CMS BCS Manager (Windows/Linux/MAC), Mobile App(iOS, android) |
| Motion detect | 4 |
| Privacy masking | 4 |
| Network | RJ-45 10/100Mbps |
| Compatibility | ONVIF(S/G/T) |
| Protocols | IPv4, IPv6, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x, SNMP, QoS, RTMP,SSL/TLS |
| Network security | Password protection, Strong password, HTTPS encryption, Export operation logs, Basic/digest authentication RTSP, Digest authentication HTTP, TLS 1.2, WSSE/digest authentication ONVIF |
| Power supply | PoE |
| Power supply type | 12V DC / PoE(802.3af) |
| Power consumption | max 2.8W |
| Housing color | White |
| IP class | IP67 |
| Surge protection | 4kV |
| Working environment | -30°C~+60°C max 95% RH |
| Dimensions | Ø118×106mm |
| Weight | 0.48kg |
| Ai - Perimeter protection | Crossline, intrusion |
| &Ai - Object classification | Yes |
Warning: This product belongs to the BCS POINT product line.
Use only components and devices from the same line to ensure compatibility.
BCS POINT
BCS-P-EIP26FCL3-Ai1
184,50 € gross
100 In Stock- 6Mpx dome IP camera
- 1/1.8" PS CMOS sensor
- NightColor technology
- NDAA compliant
- 2.8 mm fixed lens
- WDR 120 dB
- Microphone
- Whitelight 30m
- IP67-rated housing
- Built-in smart features
100 in stock
