1/2.8″ 5Mpx PS CMOS converter, H.265 / H.264 / MJPEG encoding. Supports three coding streams, ICR mechanical infrared filter. P2P, Onvif. AWB, AGC, BLC, HLC, ROI, Defog, 2D / 3D DNR, WDR (120dB) functions. 1.4mm F2.0 lens with H: 360 ° angle of view. Infrared Illuminator with a range of up to 10m. Outdoor housing IP66, IK10, microSD up to 256GB. Built-in microphone, 1 alarm input and 1 alarm output, 1 audio input and 1 audio output. Power DC12V / PoE (802.3af)
Warning: This product belongs to the BCS POINT product line.
Use only components and devices from the same line to ensure compatibility.
BCS POINT
BCS-P-FIP25FWR1
510,45 € gross
100 In Stock- 5Mpx IP camera
- 1/2.8" PS CMOS sensor
- NDAA compliant
- 1.4mm fisheye lens
- WDR 120dB
- IR 10m
- Audio 1/1, alarm 1/1, microphone
- IP66, IK10 housing
100 in stock
- DPD across Europe & worldwide — free in the EU from 1000,00 € (ex. VAT)
- Official BCS e-commerce Business Partner
- Technical support
| Product | BCS-P-FIP25FWR1 |
|---|---|
| NDAA | National Defense Authorization Act |
| Recording in BCS CLOUD | Yes |
| Camera type | Fisheye |
| Resolution | 5 Mpx |
| Sensor | 1/2.8'' CMOS |
| Scanning system | Progressive Scan |
| Pixels | 2880(H)×1620(V) |
| Lens | Fisheye |
| Focal length | 1.4 mm |
| Aperture | F2.0 |
| Focus | fixed |
| Iris | fixed |
| Digital zoom | 16× |
| Angle of view | H: 360° |
| DORI | Detect 31m / Observe 13m/ Recognize 6m/ Identify 3m |
| Min illumination | 0.01Lux(F2.0,AGC) 0Lux(F1.4,B/W,IR) |
| S/N ratio | 55dB |
| White balance | (AWB) Auto / manual |
| WDR | 120dB |
| Backlight compensation | BLC / HLC / WDR(120dB) |
| Shutter | Auto / manual 1~1/100000s |
| Gain control | (AGC) Auto / manual |
| Noise reduction | 2D/3D DNR |
| Image rotate | Mirror, flip 180° |
| Stream support | 3 |
| Resolutions | 5M(2880×1620) / 4M(2560×1440) / 3M(2304×1296) / 2M(1920×1080) / 720P(1280×720) / D1(720×576) / (640×360) / 2CIF(704×288) / CIF(352×288) |
| Main stream | 2880×1620@30fps 2560×1440@30fps 2304×1296@30fps 1920×1080@30fps 1280×720@30fps |
| Second stream | 1920×1080@30fps 1280×720@30fps 640×360@30fps |
| Third stream | 720×576@30fps 640×360@30fps 704×288@30fps 352×288@30fps |
| Bitrate | 128Kbps~6144kbps |
| Video compression | H.265 / H.265+ / H.264 / H.264+ / MJPEG |
| Day/night | ICR |
| Illuminator type | IR LED |
| IR range | 10m |
| Microphone | Yes |
| Audio compression | G.711 |
| Memory card slot | microSD 256GB |
| Support | Web Service, CMS BCS Manager (Windows/Linux/MAC), Mobile App(iOS, android) |
| Motion detect | 4 |
| Privacy masking | 4 |
| Network | RJ-45 10/100Mbps |
| Compatibility | ONVIF(S/G/T) |
| Protocols | IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x, SNMP, QoS, RTMP, SSH |
| Network security | |
| Power supply | PoE |
| Power supply type | 12V DC / PoE(802.3af) |
| Power consumption | max 8.5W |
| Housing color | White |
| IP class | IP66 |
| IK10 | Yes |
| Working environment | -30°C~+60°C max 95% RH |
| Dimensions | Ø125mm×43.7mm |
| Weight | 0.36kg |
