Display and recording of up to 16 IP cameras at a maximum resolution of 12Mpx, H.265 + / H265 / H.264 + / H.264 compression, maximum incoming bandwidth 320Mbps outgoing 320Mbps, HDMI 4K video output and 1080P VGA, advanced video detection: motion detection screening, image loss, support for intelligent camera functions: face detection, people counting, intrusion into the area, line crossing, audio detection, fisheye dewraping mode, support for 2 SATA disks up to 6 TB each, 3 × USB, RS485, 2 × RJ45, 1 audio input and 1 audio output, 8 alarm inputs and 2 alarm outputs, built-in web server, support via CMS (BCS Manager), BCS mobile application (iOS, android), P2P, Onvif, power supply 12V DC.
Warning: This product belongs to the BCS POINT product line.
Use only components and devices from the same line to ensure compatibility.
BCS POINT
BCS-P-NVR1602-A-4K-III
479,70 € gross
Out of Stock- 16-channel IP recorder
- Compliance with the NDAA
- Supports 2 hard drives
- Supports 12Mpx IP cameras
- 8/2 alarm channels, 1/1 audio channels
- HDMI 4K/VGA output
Out of stock
This product is out of stock right now. Leave your e-mail and we will let you know when it is back — or propose an equivalent.
| Weight (without HDD) | 1.8kg |
|---|---|
| Pentaplex function | Live view / recording / playback / archiving / remote access |
| HDD support | 2 |
| Incoming bandwidth | 320Mbps |
| Power consumption (without HDD) | max 12W |
| Video compression | H.265+ / H265 / H.264+ / H.264 |
| Product | BCS-P-NVR1602-A-4K-III |
| System | IP |
| Channels | 16 |
| HDD capacity | 8 TB |
| Max recording resolution | 12 Mpx |
| Outgoing bandwidth | 320Mbps |
| Display efficiency | 1×12M(30fps) / 2×8M(30fps) / 5×4M(30fps) / 10×2M(30fps) / 16×720p(30fps) |
| Recording resolutions | 12M / 8M / 6M / 5M / 4M / 3M / 2M / 960p / 720p / D1 / 2CIF / CIF |
| VGA display resolutions | 1920×1080 / 1600×1200 / 1280×1024 / 1280×720 / 1024×768 |
| HDMI out | HDMI4K |
| VGA out | VGA |
| HDMI display resolutions | 3840×2160 / 1920×1080 / 1600×1200 / 1280×1024 / 1280×720 / 1024×768 |
| Display split | 1/4/8/9/16 (3/4/5/7/9/10/12/16 corridor mode) |
| Fisheye Dewarping | Yes |
| Synchronous playback | 1/4/9/16 |
| Archiving | Possibility to download material to external media such as USB FLASH, USB HDD |
| User connections | 128 |
| Interfaces | 2×USB2.0, 1×USB3.0 |
| Serial port | RS485 |
| Audio in | 1 |
| Audio out | 1 |
| Audio compression | G.711A / G.711U |
| Alarm in | 8 |
| Alarm out | 2 |
| Support | Local, Web Service, CMS BCS Manager (Windows/Linux/MAC), Mobile App(iOS, android) |
| Network | 2×RJ-45 10/100/1000Mbps |
| Compatibility | ONVIF(S/G/T), support third party cameras |
| Protocols | TCP/IP, P2P, UPnP, NTP, DHCP, PPPoE, HTTP, HTTPS, DNS, DDNS, SNMP, SMTP, NFS |
| Power supply | 12V DC |
| Working environment | -10°C~+55°C max 90% RH |
| Casing | 1U |
| Dimensions (W×D×H) | 380×315×49mm |
