| Ai - Human/vehicle detection | Human recognition for intrusion in the target area reduces false alarms. |
|---|---|
| Camera type | Panoramic |
| Sensor | 2 × 1/2.9'' CMOS |
| Lens | fixed |
| Iris | fixed |
| Min illumination | 0.0005Lux(F1.0,AGC) |
| Backlight compensation | BLC / HLC / DWDR |
| Ai - Built-in intelligent functions | Built-in intelligent algorithm of image analisis |
| Defog | Digital |
| Product | BCS-P-PTIP2X2FCL3-Ai |
| NDAA | National Defense Authorization Act |
| Resolution | 4 Mpx |
| Scanning system | Progressive Scan |
| Pixels | 3840(H)×1080(V) |
| Focal length | 2 × 4 mm |
| Aperture | F1.0 |
| Focus | fixed |
| Digital zoom | 16× |
| Angle of view | H: 160° V: 43.22° D: 180.1° |
| DORI | Detect 64m / Observe 26m / Recognize 13m / Identify 6m |
| S/N ratio | 56dB |
| White balance | (AWB) Auto / manual |
| WDR | DWDR |
| Shutter | Auto / manual 1~1/100000s |
| Gain control | (AGC) Auto / manual |
| Noise reduction | 2D/3D DNR |
| RoI | Region of Interest |
| Stream support | 2 |
| Resolutions | 4M(3840×1080) / 2M(1920×540) |
| Main stream | 3840×1080@25fps |
| Second stream | 1920×540@25fps |
| Bitrate | 128Kbps~16Mbps |
| Video compression | H.265 / H.265+ / H.264 / H.264+ / MJPEG |
| Illuminator type | WhiteLight |
| WhiteLight range | 30m |
| NightColor | Yes |
| Microphone | Yes |
| Loudspeaker | Yes |
| Audio in | 1 |
| Audio out | 1 |
| Audio compression | G.711A / G.711U |
| Alarm in | 1 |
| Alarm out | 1 |
| Storage | NAS(NFS) |
| Memory card slot | microSD 256GB |
| Support | Web Service, CMS BCS Manager (Windows/Linux/MAC), Mobile App(iOS, android) |
| Motion detect | 4 |
| Privacy masking | 4 |
| Network | RJ-45 10/100Mbps |
| Compatibility | ONVIF(S/G/T) |
| Protocols | IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x, SNMP, QoS, RTMP, SSL/TLS, SSH |
| Network security | Password protection, Strong password, HTTPS encryption, Export operation logs, Basic/digest authentication RTSP, Digest authentication HTTP, TLS 1.2, WSSE/digest authentication ONVIF |
| Power supply | PoE |
| Power supply type | 12V DC / PoE(802.3af) |
| Power consumption | max 6.5W |
| Housing color | White |
| IP class | IP67 |
| IK10 | Yes |
| Surge protection | 4kV |
| Working environment | -30°C~+60°C max 95% RH |
| Dimensions | 273×130×76mm |
| Weight | 0.95kg |
| Casing | Metal |
| &Ai - Object classification | Yes |
Warning: This product belongs to the BCS POINT product line.
Use only components and devices from the same line to ensure compatibility.
BCS POINT
BCS-P-PTIP2X2FCL3-Ai
355,47 € gross
62 In Stock- 4Mpx panoramic IP bullet camera
- 2×1/2.9" PS CMOS sensor
- NightColor technology
- NDAA compliance
- 2x 4mm fixed lens
- WhiteLight 30m
- Alarm 1/1, audio 1/1, microphone, speaker
- IP67, IK10 housing
- Built-in smart features
62 in stock
- DPD across Europe & worldwide — free in the EU from 1000,00 € (ex. VAT)
- Official BCS e-commerce Business Partner
- Technical support
