5Mpx PTZ rotary WiFi IP camera. 1/2.7″ Starlight sensor with motozoom 2.7 ~ 13.5mm lens, microphone, speaker and 5x zoom. Compression: H.265 / H.265 + / H.264 / H264 + / MJPEG. Resolution 5Mpx, IR illuminator up to 30m, progressive scan , 256GB microSD memory card slot. 1 Alarm Input and 1 Alarm Output, RS485. Motion detection, automatic tracking, object recognition, face detection, perimeter protection, privacy mask, web service. White housing. Power supply: DC 12V / PoE (802.3 at).
Warning: This product belongs to the BCS POINT product line.
Use only components and devices from the same line to ensure compatibility.
BCS POINT
BCS-P-SIP155SR3-Ai2
428,04 € gross
2 In Stock- 5Mpx pan-tilt IP camera
- Wi-Fi (IEEE 802.11b/g/n)
- 1/2.7" PS CMOS sensor
- SkyLight technology
- NDAA compliant
- 2.7–13.5 mm motorised zoom lens
- 5x optical zoom
- WDR 120dB
- IR 30m
- Alarm 1/1, microphone, speaker
- Built-in smart features
2 in stock
- DPD across Europe & worldwide — free in the EU from 1000,00 € (ex. VAT)
- Official BCS e-commerce Business Partner
- Technical support
| Ai - Human/vehicle detection | Human/vehicle classification for crossline and intrusion reduces false alarms |
|---|---|
| Recording in BCS CLOUD | Yes |
| Resolution | 5 Mpx |
| Pixels | 2880(H)×1620(V) |
| Focus | Auto / manual |
| Angle of view | H:106.9°~30.6°V:56.0°~17.7° D:131.5°~39.8° |
| White balance | (AWB) Auto / manual |
| Ai - Built-in intelligent functions | Built-in intelligent algorithm of image analisis |
| Noise reduction | 2D/3D DNR |
| Product | BCS-P-SIP155SR3-Ai2 |
| NDAA | National Defense Authorization Act |
| Camera type | PTZ |
| Sensor | 1/2.7'' CMOS |
| Scanning system | Progressive Scan |
| Lens | motozoom |
| Focal length | 2.7~13.5 mm |
| Aperture | F 1.2 |
| Iris | Auto |
| Optical zoom | 5× |
| Digital zoom | 16× |
| DORI | Detect 71~247m / Observe 28~99m / Recognize 14~49m / Identify 7~25m |
| Min illumination | 0.003Lux(F1.2,AGC) 0Lux(B/W,IR) |
| S/N ratio | 56dB |
| Third stream | 720×576 / 640×360 / 704×288 / 352×288 (25/30fps) |
| WDR | 120dB |
| Backlight compensation | BLC / HLC / WDR(120dB) |
| Shutter | Auto / manual 1~1/100000s |
| Gain control | (AGC) Auto / manual |
| Image rotate | Mirror, Flip 0°/90°/180°/270° |
| Stream support | 3 |
| Resolutions | 5M(2880×1620) / 2M(1920×1080) / 720P(1280×720) / D1(720×576) / 2CIF(704×288) / (640×360) / CIF(352×288) |
| Main stream | 2880×1620 / 1920×1080 / 1280×720(25/30fps) |
| Second stream | 1920×1080 / 1280×720 / 720×576 / 704×288 / 640×360 / 352×288(25/30fps) |
| Bitrate | 128Kbps~16Mbps |
| Video compression | H.265 / H.265+ / H.264 / H.264+ / MJPEG |
| Day/night | ICR mechanical infrared filter |
| Illuminator type | IR LED |
| IR range | 30m |
| Microphone | Yes |
| Loudspeaker | Yes |
| Audio compression | G.711U / G.711A |
| Alarm in | 1 |
| Alarm out | 1 |
| Memory card slot | microSD 256GB |
| Other interfaces | RS485 |
| Support | Web Service, CMS BCS Manager (Windows/Linux/MAC), Mobile App(iOS, android) |
| Motion detect | 4 |
| Privacy masking | 24 |
| Network | RJ-45 10/100 Mbps |
| Wi-Fi | 802.11b/g/n 2.4GHz |
| Compatibility | ONVIF(S/G/T) |
| Protocols | IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x, SNMP, QoS, RTMP, SSL/TLS |
| Network security | HTTPS, SSL, TLS, Digest Authentication, Login Authentication, Account Lockout, IP address filtering, ARP protection |
| Power supply | PoE |
| Power supply type | 12V DC / PoE(802.3at) |
| Power consumption | max 15W |
| Housing color | White |
| Surge protection | TVS 4kV |
| Working environment | -10°C~+50°C max 95% RH |
| Dimensions | Ø129mm×143.6mm |
| Weight | 0.76 kg |
| PAN speed | 0.1°/s~60°/s(60°/s preset) |
| TILT speed | 0.1°/s~50°/s(50°/s preset) |
| PAN range | 0°~350° |
| TILT range | 0°~90° |
| Ai - Perimeter protection | Crossline, intrusion |
| &Ai - Object classification | Yes |
| Ai - Face detection | Face detection and tracking, snapshot |
| Ai - People counting | People counting for intrusion and crossline, counting people in/out |
