BCS — Est. 2008 Decades of expertise A diverse portfolio developed across Europe

Warning: This product belongs to the BCS ULTRA product line.
Use only components and devices from the same line to ensure compatibility.

BCS-U-SNVR0401-4P
BCS-U-SNVR0401-4P - Image 2
BCS-U-SNVR0401-4P - Image 3
BCS-U-SNVR0401-4P - Image 4
BCS-U-SNVR0401-4P - Image 5
BCS ULTRA

BCS-U-SNVR0401-4P

495,69 € gross

Out of Stock
  • 4-channel IP recorder
  • Compliance with the NDAA
  • SMART housing
  • Built-in 4-port 30W PoE switch
  • Supports 1 hard drive
  • Supports 8Mpx IP cameras
  • HDMI/VGA output

Out of stock

This product is out of stock right now. Leave your e-mail and we will let you know when it is back — or propose an equivalent.

SKU: 12015 Categories: , , ,
Flag

TO ORDER
Product

BCS-U-SNVR0401-4P
NDAA

National Defense Authorization Act
System

IP
Pentaplex function

Live view / recording / playback / archiving / remote access
Channels

4
HDD support

1
HDD capacity

10 TB
Record mode

Continuous, manual, alarm, motion detection, schedule, Ai
Max recording resolution

8 Mpx
Incoming bandwidth

60Mbps
Video compression

H.265+ / H265 / H.264+ / H.264
HDMI out

HDMI
VGA out

VGA
HDMI display resolutions

1920×1200 / 1920×1080 / 1680×1050 / 1600×1200
VGA display resolutions

1920×1200 / 1920×1080 / 1680×1050 / 1600×1200
Display split

1/2/3/4
Synchronous playback

4
Archiving

Possibility to download material to external media such as USB FLASH, USB HDD
Interfaces

2×USB2.0
Support

Local, Web Service, CMS BCS Manager (Windows/Linux/MAC), Mobile App(iOS, android)
Network

RJ-45 10/100Mbps
Compatibility

ONVIF, support third party cameras
Network security

DirectIP, SSL, TLS, FEN, iBank, Firewall, Chained Fingerprint, IPC separated network
Standard

IEEE 802.3 af/at
Switch PoE power

30W
PoE channels

4
Power supply

48~56V DC
pa_power-consumption-with-f3386

max 40.8W
Working environment

0°C~+40°C max 90% RH
Casing

smart
Dimensions (W×D×H)

205×44.5×216.4mm
Weight (without HDD)

1.2 kg
