| Power consumption (without HDD) | max 10W |
|---|---|
| &Ai - Built-in intelligent functions | Yes |
| Ai - Intelligent functions from recorder | intelligent motion detection (person/vehicle recognition), face detection and face identification, perimeter protection (person/vehicle recognition) |
| Ai - Intelligent functions from camera | Intelligent motion detection (person/vehicle recognition), face identification, perimeter protection (person/vehicle recognition), ARTR |
| Ai - SMD - Smart Motion Detection | 8 channels 4Mpx |
| Product | BCS-V-NVR0801-A-4KE(3) |
| System | IP |
| Pentaplex function | Live view / recording / playback / archiving / remote access |
| Channels | 8 |
| HDD support | 1 |
| HDD capacity | 10 TB |
| Max recording resolution | 12 Mpx |
| Incoming bandwidth | 80Mbps |
| Outgoing bandwidth | 80Mbps |
| Display efficiency | 1×12M(30fps) / 2×8M(30fps) / 4×4M(30fps) / 8×2M(30fps) Ai: 1×12M(30fps) / 1×8M(30fps) / 3×4M(30fps) / 6×2M(30fps) |
| Recording resolutions | 12M / 8M / 6M / 5M / 4M / 3M / 2M / UXGA / 720P / VGA / 4CIF / DCIF / 2CIF / CIF / QCIF |
| Video compression | H.265+ / H265 / H.264+ / H.264 |
| HDMI out | HDMI4K |
| VGA out | VGA |
| HDMI display resolutions | 3840×2160 / 2560×1440 / 1920×1080 / 1600×1200 / 1280×1024 / 1280×720 / 1024×768 |
| VGA display resolutions | 1920×1080 / 1280×1024 / 1280×720 |
| Display split | 1/4/8 |
| Synchronous playback | 1/4/8 |
| Archiving | Possibility to download material to external media such as USB FLASH, USB HDD |
| User connections | 128 |
| Interfaces | 2×USB2.0 |
| Audio in | 1 |
| Audio out | 1 |
| Audio compression | G.711ulaw/G.711alaw/G.722/G.726/AAC |
| Alarm in | 4 |
| Alarm out | 1 |
| Support | Local, Web Service, CMS BCS Manager (Windows/Linux/MAC), Mobile App(iOS, android) |
| Network | RJ-45 10/100/1000Mbps |
| Compatibility | ONVIF, support third party cameras |
| Protocols | TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP, HTTP, HTTPS |
| Power supply | 12V DC |
| Working environment | -10°C~+55°C max 90% RH |
| Casing | 1U |
| Dimensions (W×D×H) | 320×240×48mm |
| Weight (without HDD) | 1 kg |
| Ai - Perimeter protection | 1 channel 4Mpx (person/vehicle recognition) |
| &Ai - Object classification | Yes |
| Ai - Face detection | 1 channel 8Mpx |
| &Ai - SMD | Yes |
| Ai - Face recognition | 4 recognition channels, 16 databases, 20k. pictures (max 4MB, total 1GB) |
Warning: This product belongs to the BCS VIEW product line.
Use only components and devices from the same line to ensure compatibility.
BCS VIEW
BCS-V-NVR0801-A-4KE(3)
361,62 € gross
Out of Stock- 8-channel IP recorder
- AcuSense technology
- Supports 1 hard drive
- Supports 12Mpx IP cameras
- HDMI 4K/VGA output
- Audio 1/1, Alarm 4/1
- Built-in smart features
Out of stock
This product is out of stock right now. Leave your e-mail and we will let you know when it is back — or propose an equivalent.
