| Power consumption (without HDD) | max 15W |
|---|---|
| &Ai - Built-in intelligent functions | Yes |
| Ai - Intelligent functions from recorder | intelligent motion detection (person/vehicle recognition), face detection and face identification, perimeter protection (person/vehicle recognition) |
| Ai - Intelligent functions from camera | Intelligent motion detection (person/vehicle recognition), face identification, perimeter protection (person/vehicle recognition), ARTR |
| Ai - SMD - Smart Motion Detection | 8 channels 4Mpx |
| Product | BCS-V-NVR0802-A-4KE-8P(3) |
| System | IP |
| Pentaplex function | Live view / recording / playback / archiving / remote access |
| Channels | 8 |
| HDD support | 2 |
| HDD capacity | 16 TB |
| Max recording resolution | 12 Mpx |
| Incoming bandwidth | 80Mbps |
| Outgoing bandwidth | 160Mbps |
| Display efficiency | 2×12M(30fps) / 4×8M(30fps) / 8×4M(30fps) Ai: 2×12M(30fps) / 3×8M(30fps) / 6×4M(30fps) / 8×2M(30fps) |
| Recording resolutions | 12M / 8M / 6M / 5M / 4M / 3M / 2M / UXGA / 720P / VGA / 4CIF / DCIF / 2CIF / CIF / QCIF |
| Video compression | H.265+ / H265 / H.264+ / H.264 |
| HDMI out | HDMI4K |
| VGA out | VGA |
| HDMI display resolutions | 3840×2160 / 2560×1440 / 1920×1080 / 1600×1200 / 1280×1024 / 1280×720 |
| VGA display resolutions | 1920×1080 / 1280×1024 / 1280×720 |
| Display split | 1/4/8 |
| Synchronous playback | 1/4/8 |
| Archiving | Possibility to download material to external media such as USB FLASH, USB HDD |
| User connections | 128 |
| Interfaces | 2×USB2.0 |
| Audio in | 1 |
| Audio out | 1 |
| Audio compression | G.711ulaw/G.711alaw/G.722/G.726/AAC |
| Alarm in | 4 |
| Alarm out | 1 |
| Support | Local, Web Service, CMS BCS Manager (Windows/Linux/MAC), Mobile App(iOS, android) |
| Network | RJ-45 10/100/1000Mbps |
| Compatibility | ONVIF, support third party cameras |
| Protocols | TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP, HTTP, HTTPS |
| Standard | IEEE 802.3 af/at |
| Switch PoE power | 80W |
| PoE channels | 8 |
| Power supply | 48V DC |
| Working environment | -10°C~+55°C max 90% RH |
| Casing | 1U |
| Dimensions (W×D×H) | 385×315×52mm |
| Weight (without HDD) | 3 kg |
| Ai - Perimeter protection | 2 kanały 4Mpx (rozpoznawanie osoba/pojazd mechaniczny) |
| &Ai - Object classification | Yes |
| Ai - Face detection | 1 channel 8Mpx |
| &Ai - SMD | Yes |
| Ai - Face recognition | 4 recognition channels, 16 databases, 20k. pictures (max 4MB, total 1GB) |
Warning: This product belongs to the BCS VIEW product line.
Use only components and devices from the same line to ensure compatibility.
BCS VIEW
BCS-V-NVR0802-A-4KE-8P(3)
490,77 € gross
Out of StockOut of stock
This product is out of stock right now. Leave your e-mail and we will let you know when it is back — or propose an equivalent.
