1/1.8″ 4Mpx PS CMOS sensor, NightColor technology, resolution 2688 × 1520 @ 30fps, H.265 + / H.264 + / MJPEG compression, ICR mechanical infrared filter, AGC, AWB, AES, BLC, HLC, WDR functions ( 130dB), 3D, DNR, ROI, intelligent functions, 2.8mm F1.0 fixed focal lens, infrared LEDs with a range of up to 60m, microSD up to 256GB, IP67 metal external housing, operating conditions -30 ° C ~ + 60 ° C, DC 12V power supply, PoE (802.3af).
Warning: This product belongs to the BCS VIEW product line.
Use only components and devices from the same line to ensure compatibility.
BCS VIEW
BCS-V-TIP54FCL6-Ai2
480,93 € gross
Out of Stock- 4Mpx IP bullet camera
- 1/1.8" PS CMOS sensor
- NightColor technology
- AcuSense technology
- ADC technology
- 2.8mm fixed lens
- WDR 130dB
- WhiteLight 60m
- IP67-rated housing
- Built-in smart features
Out of stock
This product is out of stock right now. Leave your e-mail and we will let you know when it is back — or propose an equivalent.
| Ai - Human/vehicle detection | Human/vehicle classification for crossline and intrusion reduces false alarms |
|---|---|
| Product | BCS-V-TIP54FCL6-Ai2 |
| Camera type | Bullet |
| Scanning system | Progressive Scan |
| Focal length | 2.8 mm |
| Iris | fixed |
| Min illumination | 0.0005Lux(F1.0, AGC) |
| Ai - Built-in intelligent functions | Built-in intelligent algorithm of image analisis |
| Shutter | Auto / manual 1/3~1/100000s |
| Active deterrence function ADC | Optical alarm |
| Resolution | 4 Mpx |
| Sensor | 1/1.8'' CMOS |
| Pixels | 2688(H)×1520(V) |
| Lens | fixed |
| Aperture | F 1.0 |
| Focus | fixed |
| Digital zoom | 16× |
| Angle of view | H: 112° V: 61° D: 134° |
| DORI | Detect 58m / Oberve 23m / Recognize 11m / Identify 2m |
| S/N ratio | 52dB |
| White balance | (AWB) Auto / manual |
| WDR | 130dB |
| Backlight compensation | BLC / HLC / WDR(130dB) |
| Resolutions | 4M(2688×1520) / 2M(1920×1080) / 720P(1280×720) / VGA(640×480) / 360P(640×360) |
| Gain control | (AGC) Auto / manual |
| Noise reduction | 3D DNR |
| Image rotate | Mirror |
| Stream support | 3 |
| Main stream | 2688×1520@30fps 1920×1080@30fps 1280×720@30fps |
| Second stream | 640×480@30fps 640×360@30fps |
| Third stream | 1920×1080@10fps 1280×720@10fps 640×480@10fps 640×360@10fps |
| Bitrate | 32Kbps~8Mbps |
| Video compression | H.265 / H.265+ / H.264 / H.264+ / MJPEG |
| Day/night | ICR |
| Illuminator type | WhiteLight |
| WhiteLight range | 60m |
| NightColor | Yes |
| Memory card slot | microSD 256GB |
| Support | Web Service, CMS BCS Manager (Windows/Linux/MAC), Mobile App(iOS, android) |
| Motion detect | Yes |
| Privacy masking | 4 |
| Network | RJ-45 10/100 Mbps |
| Compatibility | ONVIF(S/G/T) |
| Protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, ARP |
| Network security | HTTPS, SSL, TLS, IEEE802.1X, Digest authentication, IP adress filtering |
| Power supply | PoE |
| Power supply type | 12V DC / PoE (802.3af) |
| Power consumption | max 10.5W |
| Housing color | White |
| IP class | IP67 |
| Working environment | -30°C~+60°C max 95% RH |
| Dimensions | Ø105×289.5mm |
| Weight | 1.1 kg |
| Ai - Perimeter protection | Crossline, intrusion |
| &Ai - Object classification | Yes |
| Ai - Face detection | Face detection and tracking, snapshot |
