Coverage 12 × 12 m, 90° field of view,
mirror-based optical system with an elliptical lens comprising 8 independent PIR sensors in a Quad configuration, white light
immunity of over 25,000 lux, animal immunity of 18 kg, CMOS camera with IR illumination up to 10 m,
automatic brightness and contrast adjustment, mounting height from 1.5 m to 3 m on a flat surface, horizontal
adjustment from -45° to +45° and vertical adjustment from 0° to -10°,
battery life 3 years, type 2xCR17450, operating
temperature -35°C to 60°C, humidity 95% (IP54),
colour: white,
dimensions (mm): 166x147x124
. The detector is compatible with the GTI ONE, GTX2 and the Pulson Alarm 2.0 4G alarm system with the PulsON EXP-RF(PowerG) / PulsON EXP-RF(PowerG)-BOX wireless module installed.
