A wireless shock sensor with an optional magnetic reed switch and a wired input, featuring PowerG two-way communication, designed for indoor installation. Frequency
band (MHz) 868–869, alarm input, anti-tamper protection and protection against opening and severing, status monitoring at 4-minute intervals.
The tamper alarm is triggered when either of the two tamper contacts is breached. Power supply type C, battery type CR-123A lithium, 3 V. Battery
life: 5 years (for typical use); vibration detection range:
window – 4 m (double-glazed PVC windows, TBD);
timber – 3.5 m; brick or concrete walls – 2.5 m, operating temperature from –10 °C to 55 °C, storage temperature from –20 °C to 60 °C,
average relative humidity approximately 75 per cent, non-condensing. Auxiliary input
cable length: 10 m max., auxiliary input EOL resistance: 2.2 kΩ,
dimensions: 11.8 x 2.7 x 3 cm, weight (with battery): 130 g.
The detector is compatible with the GTI ONE and GTX2 systems, as well as the Pulson Alarm 2.0 4G alarm system with the PulsON EXP-RF(PowerG) / PulsON EXP-RF(PowerG)-BOX wireless module installed.
