- Fully digital PIR sensor
- Dual technology (MW + PIR), 10.525 GHz
- Compatible with any wired control panel
- Built-in EOL resistors reduce installation time and lower costs when used with PowerSeries Neo and PRO control panels
- Dual tamper protection (housings/wall)
- White light immunity and high resistance to radio frequency interference (RFI)
- Resistant to animals weighing up to 15 kg
15-metre range
100-degree field of view
Fresnel lens with LODIFF® technology and POLY IR®4 materials
LED colour: Green (PIR), Yellow (MW), Red (ALARM)
Pass test: Yes
Built-in EOL resistors: Yes, 5.6 kOhm
Dual tamper protection (wall / housing) Yes
Creep zone: Yes
Pulse counter Yes
RFI protection 30 V/m
Temperature compensation Yes
Installation Directly on the wall or using a bracket (LC-L2ST)
Power supply 13.8 V DC
Current consumption 27 mA
Animal resistance: Yes, up to 15 kg
Dimensions 114 x 63 x 40 mm
MW frequency 10.525 GHz
