| Product | BCS-B-SIP155SR5L1-Ai1(2.0) |
|---|---|
| pa_product-line | BCS BASIC |
| Camera type | PTZ |
| Resolution | 5 Mpx |
| Sensor | 1/2.7'' CMOS |
| Scanning system | Progressive Scan |
| Pixels | 2880(H)×1620(V) |
| Lens | motozoom |
| Focal length | 2.7~13.5 mm |
| Aperture | F1.6 |
| Focus | Auto / manual |
| Iris | Auto / manual |
| Optical zoom | 5× |
| Digital zoom | 16× |
| Angle of view | H:106.91°~33.55° V:56.45°~18.99° D:123.1°~42.1° |
| DORI | Detect 72~229.5m / Observe 28.8~91.8m / Recognize 14.4~45.9m / Identify 7.2~23m |
| Min illumination | 0.005Lux(Color,F1.6,AGC) 0Lux(B/W,IR) |
| S/N ratio | 56dB |
| White balance | (AWB) Auto / manual |
| WDR | 120dB |
| Backlight compensation | BLC / HLC / WDR(120dB) |
| Shutter | Auto / manual 1/30~1/100000s |
| Gain control | (AGC) Auto / manual |
| Noise reduction | 2D/3D DNR |
| RoI | Region of Interest |
| Defog | Electronic |
| Image rotate | Mirror, Flip |
| Stream support | 2 |
| Main stream | 2880×1620(25/30fps) |
| Second stream | 1280×720(25/30fps) |
| Bitrate | 128Kbps~16Mbps |
| Video compression | H.265 / H.265+ / H.264+ / H.264 / MJPEG |
| Day/night | ICR mechanical infrared filter |
| Illuminator type | IR LED + WhiteLight |
| IR range | 50m |
| WhiteLight range | 15m |
| NightColor | Yes |
| Microphone | Yes |
| Loudspeaker | Yes |
| pa_active-deterrence-functio | Sound-optical alarm |
| pa_warning-lights | Red/Blue Light |
| Audio in | 1 |
| Audio out | 1 |
| Audio compression | G.711A / G.711U |
| Alarm in | 1 |
| Alarm out | 1 |
| Storage | ANR, NAS(NFS) |
| Memory card slot | microSD 512GB |
| Support | Web Service, CMS BCS Manager (Windows/Linux/MAC), Mobile App(iOS, android) |
| Motion detect | Yes |
| Privacy masking | 4 |
| Network | RJ-45 10/100 Mbps |
| Compatibility | ONVIF(S/G/T/M) |
| Protocols | TLS1.3, SSH, IGMP, RTP, RTCP, SMTP, IPv4, IPv6, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTSP, RTMP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, 802.1x, SNMP, QoS, SSL/TLS |
| Network security | Password Protection, Strong Password, HTTPS Encryption, Export Operation Logs, Basic and Digest Authentication for RTSP, Digest Authentication for HTTP, TLS 1.2, WSSE and Digest Authentication for ONVIF |
| Power supply | PoE |
| Power supply type | 12V DC / PoE(802.3at) |
| Power consumption | max 18W |
| Housing color | White |
| IP class | IP66 |
| Built-in heater | Yes |
| Surge protection | TVS 2kV |
| Working environment | -30°C~+60°C max 95% RH |
| Dimensions | 133×185×286mm |
| Weight | 0.78kg |
| PAN speed | 0.1°/s~40°/s(40°/s preset) |
| TILT speed | 0.1°/s~30°/s(30°/s preset) |
| PAN range | 0°~345° |
| TILT range | -10°~100° |
| Auto tracking | Yes |
| Automatic functions | 1024 presety, 16 tras(po 64 presety) |
| pa_ai-built-in-intelligent-f | Built-in intelligent algorithm of image analisis |
| Ai - Perimeter protection | Crossline, intrusion |
| &Ai - Object classification | Yes |
| pa_ai-human-vehicle-detectio | Human/vehicle classification for crossline and intrusion reduces false alarms |
| Accessories included | integrated Wall mount |
BCS-B-SIP155SR5L1-Ai1(2.0)
225,09 € gross
100 In Stock- 5Mpx pan-tilt IP camera
- ADC technology
- 1/2.7" PS CMOS sensor
- SkyLight technology
- 2.7–13.5 mm motorised zoom lens
- 5x optical zoom
- WDR 120 dB
- IR 50m, WhiteLight 15m
- Microphone, speaker
- IP66-rated housing
- Built-in smart features
100 in stock
- DPD across Europe & worldwide — free in the EU from 1000,00 € (ex. VAT)
- Official BCS e-commerce Business Partner
- Technical support
