8-port managed switch (8 × PoE) 1000Mbps + 2 × Gigabit SFP with 4 operating modes
Warning: This product belongs to the BCS BASIC product line.
Use only components and devices from the same line to ensure compatibility.
BCS BASIC
BCS-B-SP08G-2SFP-M
184,50 € gross
100 In Stock8-port managed PoE switch
- exPoE technology
- 8xPoE 1Gbps af/at
- 2x 1Gbps SFP uplinks
- Total power 150W
- Modes: standard/VLAN/extend/QoS/PoE
100 in stock
- DPD across Europe & worldwide — free in the EU from 1000,00 € (ex. VAT)
- Official BCS e-commerce Business Partner
- Technical support
| Product | BCS-B-SP08G-2SFP-M |
|---|---|
| PoE ports | 8×RJ45 1Gbps |
| Uplink ports | 2×SFP 1Gbps |
| Managed | Yes |
| Management port | 1×RJ45 |
| Management functions | |
| Standard IEEE | 802.3af / 802.3at |
| Transfer | 10/100/1000Mbps half-duplex, full-duplex, auto-negotiation, auto MDI/MDIX |
| Packet forwarding rate | 14.8Mpps |
| Capacity | 20Gbps |
| STANDARD mode | 100m |
| VLAN mode | VLAN mode ports 1-8 isolated |
| EXTEND mode | EXTEND mode ports 1-8 support transmission 250m 10Mbps (cat5e, cat6) |
| QoS mode | QOS Quality Of Service – priority video pockets |
| PoE mode | Monitoring ports supply PoE devices and automatic restart with power supply cut when not responding |
| PoE pin | 1,2(+), 3,6(-) |
| LED status | PWR(red): power supply connected, LINK/ACT(green): device connected, PoE(yellow): device powered from PoE, SYS(green blink): System status |
| PoE switch power | 150W max 46W/port |
| Power supply | 100~240V AC |
| Working environment | 0°C~+40°C max 90% RH |
| Weight | 1.3 kg |
| Casing | 1U |
| Dimensions (W×D×H) | 285×180×44mm |
