| Product | BCS-L-SP0802G(II) |
|---|---|
| PoE ports | 8×RJ45 100Mbps |
| Uplink ports | 2×RJ45 1Gbps |
| Standard IEEE | 802.3af / 802.3at / 802.3bt / 802.3 / 802.3u / 802.3x / 802.3ab |
| Transfer | 10/100/1000Mbps half-duplex, full-duplex, auto-negotiation |
| Packet forwarding rate | 4.17Mpps |
| Capacity | 5.6Gbps |
| MAC table | 8K |
| Packet buffer memory | 1Mbit |
| STANDARD mode | 100m |
| EXTEND mode | EXTEND mode suppport transmission 250m 10Mbps (cat5e, cat6) |
| PoE pin | 1,2,4,5(+), 3,6,7,8(-) |
| LED status | PWR(green): power supply connected, LINK/ACT(green): device connected, PoE(yellow): device powered from PoE |
| PoE switch power | 96W (port 1 max 90W / port 2-8 max 30W) |
| Protection | Electrostatic 8kV environment / 6kV contact, 2kV DM / 4kV surge protection CM |
| Power supply | 53V DC |
| Working environment | -10°C~+55°C max 95% RH |
| Weight | 0.5 kg |
| Casing | Desktop |
| Dimensions (W×D×H) | 190×100×30mm |
Warning: This product belongs to the BCS LINE product line.
Use only components and devices from the same line to ensure compatibility.
Save 56%
BCS LINE
BCS-L-SP0802G(2)
78,88 € gross
6 In Stock8-port PoE switch
- exPoE technology
- 8xPoE 100Mbps af/at
- 1 x 802.3bt 90W PoE port
- 2xRJ45 1Gbps uplink
- Total power: 96W
- Standard/Extend modes
6 in stock
- DPD across Europe & worldwide — free in the EU from 1000,00 € (ex. VAT)
- Official BCS e-commerce Business Partner
- Technical support
