32-channel 4-disk HDCVI / AHD / TVI / ANALOG / IP recorder with 5 systems.
Warning: This product belongs to the BCS LINE product line.
Use only components and devices from the same line to ensure compatibility.
BCS LINE
BCS-L-XVR3204-4KE-IV
3094,68 € gross
2 In Stock- 32-channel, 5-system recorder
- HDCVI/AHD/TVI/ANALOGUE/IP
- Supports 4 hard drives
- Supports 8Mpx analogue HD and 12Mpx IP cameras.
- HDMI 4K/HDMI/VGA output
- 16/6 alarm channels, 4/1 audio channels
- Built-in smart features
2 in stock
- DPD across Europe & worldwide — free in the EU from 1000,00 € (ex. VAT)
- Official BCS e-commerce Business Partner
- Technical support
| Power consumption (without HDD) | max 22W |
|---|---|
| Ai - Built-in intelligent functions | Yes |
| Ai - Intelligent functions from recorder | Perimeter protection (human/vehicle recognition), smart motion detection (human/vehicle recognition), face detection, face recognition |
| Ai - SMD - Smart Motion Detection | 32 channels analog HD |
| Flag | TO ORDER |
| Product | BCS-L-XVR3204-4KE-IV |
| Transmission standard | HD-CVI / AHD / HD-TVI / ANALOG / IP |
| System | Analog HD + IP |
| Pentaplex function | Live view / recording / playback / archiving / remote access |
| Channels | 32 |
| HDD support | 4 |
| HDD capacity | 16 TB |
| Max recording resolution | 8 Mpx |
| Incoming bandwidth | 128Mbps |
| Outgoing bandwidth | 128Mbps |
| HD-CVI camera | 8M, 6M, 5M, 4M, 1080P@25/30fps, 720P@25/30/50/60fps |
| AHD camera | 8M, 5M, 4M, 3M, 1080P@25/30, 720P@25/30fps |
| HD-TVI camera | 8M, 5M, 4M, 3M, 1080P@25/30, 720P@25/30fps |
| ANALOG camera | CVBS PAL/NTSC |
| XVR - IP camera | 12M |
| XVR - IP channels | 32 |
| Recording resolutions | 8M / 6M / 5M / 4K Lite / 4M / 3M / 4M Lite / 1080P / 720P / 960H / D1 / CIF |
| Main stream | 8M(7fps), 6M(10fps), 5M(12fps), 4K Lite/4M/3M(15fps), 4M Lite/1080P/720P/960H/D1/CIF(25/30fps) |
| Second stream | 960H(15fps), D1/CIF(25/30fps) |
| Bitrate | 32Kbps~6144Kbps |
| Video compression | H.265+ / H265 / H.264+ / H.264 / Ai coding |
| HDMI out | HDMI4K/HDMI |
| VGA out | VGA |
| HDMI display resolutions | 3840×2160 / 1920×1080 / 1280×1024 / 1280×720 / 1024×768 |
| VGA display resolutions | 1920×1080 / 1280×1024 / 1280×720 |
| Display split | 1/4/8/9/16/25/36 |
| Synchronous playback | 1/4/9/16 |
| Archiving | Possibility to download material to external media such as USB FLASH, USB HDD |
| User connections | 128 |
| Interfaces | 1×USB2.0, 2×USB3.0, eSATA |
| Serial port | RS232, RS485 |
| Audio in | 4 |
| Audio out | 1 |
| Audio compression | G.711A / G.711U / PCM |
| Alarm in | 16 |
| Alarm out | 6 |
| Support | Local, Web Service, CMS BCS Manager (Windows/Linux/MAC), Mobile App(iOS, android) |
| Motion detect | Areas: 396(22×18) |
| Privacy masking | 4 |
| Network | RJ-45(10/100/1000Mbps) |
| Compatibility | ONVIF |
| Protocols | HTTP, HTTPS, TCP / IP, IPv4, RTSP, UDP, SMTP, NTP, DHCP, DNS, DDNS, P2P |
| Power supply | 100~240V AC |
| Working environment | -10°C~+55°C max 90% RH |
| Casing | 1.5U |
| Dimensions (W×D×H) | 440×421×76mm |
| Weight (without HDD) | 4.7 kg |
| POS | Yes |
| Ai - Perimeter protection | 12 channels analog HD |
| &Ai - Object classification | Yes |
| Ai - Face detection | 6 channel analog HD, face attributes (gender, age, glasses, expression, mask, beard), max 12 pictures for second |
| &Ai - SMD | Yes |
| Ai - Face recognition | 6 channel analog HD, max. 12 pictures for second, up to 10 databases, 20k pictures |
