| Weight (without HDD) | 6.5 kg |
|---|---|
| Ai - Intelligent functions from camera | Face Detection/Comparison, Vehicle Detection, SIP(Intrusion/Cross Line, Enter/Leave Area), Ultra Motion Detection(UMD), Temperature(Fire/Smoking/Measurement/Smoke/Fire Detection), People Counting(People Flow, Crowd Density), Video Metadata, Traffic |
| Product | BCS-P-NVR12816R-8KR |
| NDAA | National Defense Authorization Act |
| Pentaplex function | Live view / recording / playback / archiving / remote access |
| HDD capacity | 16 TB |
| Web Service (internet explorers) | Google Chrome, Microsoft Edge, Safari or similar |
| ANR | Automatic synchronization of recordings from the camera's microSD card after the connection is lost and restored. |
| Power consumption (without HDD) | max 50W |
| Display efficiency | 2 x 32MP@30, 4 x 16MP@30, 5 x 12MP@30, 8 x 4K@30, 12 x 5MP@30, 16 x 4MP@30, 20 x 3MP@30, 32 x 1080P@30, 54 x 960P@30, 72 x 720P@30, 128 x D1 |
| System | IP |
| Channels | 128 |
| HDD support | 16 |
| &RAID | Yes |
| RAID type | 0/1/5/6/10/50/60 |
| Hot swap | Yes |
| Max recording resolution | 32 Mpx |
| Incoming bandwidth | 640Mbps |
| Outgoing bandwidth | 640Mbps |
| Recording resolutions | 32M / 16M / 12M / 8M / 6M / 5M / 4M / 3M / 2M / 960p / 720p / D1 / 2CIF / CIF |
| Video compression | H.265+ / H265 / H.264 |
| HDMI out | HDMI8K/HDMI4K |
| VGA out | 2×VGA |
| HDMI display resolutions | 7680×4320(HDMI1) / 3840×2160 / 1920×1080 / 1600×1200 / 1280×1024 / 1280×720 / 1024×768 |
| VGA display resolutions | 1920×1080 / 1600×1200 / 1280×1024 / 1280×720 / 1024×768 |
| Display split | 1/4/6/8/9/16/25/36/64 (3/4/5/7/9/10/12/16/32 corridor mode) |
| Synchronous playback | 1/4/9/16 |
| Archiving | Possibility to download material to external media such as USB FLASH, USB HDD |
| User connections | 128 |
| Interfaces | 2×USB2.0, 2×USB3.0, eSATA, 12VDC out |
| Serial port | RS232, RS485 |
| Audio in | 1 |
| Audio out | 2 |
| Audio compression | G.711A / G.711U |
| Alarm in | 16 |
| Alarm out | 10 |
| Support | Local, Web Service, CMS BCS Manager (Windows/Linux/MAC), Mobile App(iOS, android) |
| Network | 2×RJ-45 10/100/1000Mbps |
| Compatibility | ONVIF(S/G/T), support third party cameras |
| Protocols | TCP/IP, P2P, UPnP, NTP, DHCP, PPPoE, HTTP, HTTPS, DNS, DDNS, SNMP, SMTP, NFS, RTSP, 802.1x, IPv6, IPv4 |
| Cluster support | N+1 |
| Power supply | 2× 100~240V AC |
| Working environment | -10°C~+55°C max 90% RH |
| Casing | 3U |
| Dimensions (W×D×H) | 482×533×131mm |
Warning: This product belongs to the BCS POINT product line.
Use only components and devices from the same line to ensure compatibility.
BCS POINT
BCS-P-NVR12816R-8KR
5646,93 € gross
Out of Stock- 128-channel IP recorder
- Compliance with the NDAA
- Supports 16 hard drives
- Supports 32Mpx IP cameras
- 16/10 alarm channels, 2/1 audio channels
- HDMI 8K/HDMI 4K/2xVGA output
- Redundant power supply (second power supply optional)
Out of stock
This product is out of stock right now. Leave your e-mail and we will let you know when it is back — or propose an equivalent.
