| Ai - Built-in intelligent functions | Built-in intelligent algorithm of image analisis |
|---|---|
| Product | BCS-P-TIP74VSR5-ITC-0832 |
| NDAA | National Defense Authorization Act |
| Recording in BCS CLOUD | Yes |
| Camera type | Bullet |
| Resolution | 4 Mpx |
| Sensor | 1/1.8'' CMOS |
| Scanning system | Progressive Scan |
| Pixels | 2688(H)×1520(V) |
| Lens | motozoom |
| Focal length | 8~32 mm |
| Aperture | F1.7 |
| Focus | Auto / manual |
| Iris | Auto |
| Optical zoom | 4× |
| Min illumination | 0.002Lux(F1.7) |
| White balance | (AWB) Auto / manual |
| WDR | 120dB |
| Backlight compensation | BLC / WDR(120dB) |
| Shutter | Auto / manual 1/30~1/100000s |
| Gain control | (AGC) Auto / manual |
| Noise reduction | 2D/3D DNR |
| Stream support | 3 |
| Resolutions | 4M(2688×1520) / 2M(1920×1080) / 720P(1280×720) / D1(720×576) / 2CIF(704×288) / CIF(352×288) |
| Main stream | 2688×1520@30fps 1920×1080@30fps 1280×720@30fps 720×576@30fps |
| Second stream | 1280×720@30fps 720×576@30fps 704×288@30fps 352×288@30fps |
| Third stream | 720×576@30fps 704×288@30fps 352×288@30fps |
| Video compression | H.265 / H.264 |
| Day/night | ICR |
| Illuminator type | IR LED |
| IR range | 50m |
| Audio in | 1 |
| Audio out | 1 |
| Audio compression | G.711A / G.711U |
| Alarm in | 2 |
| Alarm out | 1 |
| Memory card slot | microSD 128GB |
| Other interfaces | RS485 |
| Support | Web Service, CMS BCS Manager (Windows/Linux/MAC), Mobile App(iOS, android) |
| Motion detect | 4 |
| Privacy masking | 4 |
| Network | RJ-45 10/100Mbps |
| Compatibility | ONVIF |
| Protocols | IPv4, IPv6, DHCP, SNMP, RTSP, HTTP, HTTPS, FTP, TCP, ARP, DDNS, UNP, DNS, 802.1x, WebSocket |
| Power supply | PoE |
| Power supply type | 12V DC / PoE(802.3at) |
| Power consumption | max 20W |
| Housing color | White |
| IP class | IP67 |
| IK10 | Yes |
| Working environment | -40°C~+60°C max 90% RH |
| Dimensions | 406×126×130mm |
| Weight | 2.1kg |
| Ai - ARTR | License plate recognition, photo, tracking, speed max 80km/h, black and white list 20 thousand positions |
Warning: This product belongs to the BCS POINT product line.
Use only components and devices from the same line to ensure compatibility.
BCS POINT
BCS-P-TIP74VSR5-ITC-0832
1300,11 € gross
Out of Stock- 4Mpx IP bullet camera
- ITC for number plate recognition
- 1/1.8" PS CMOS sensor
- SkyLight technology
- NDAA compliant
- 8–32 mm motorised zoom lens
- WDR 120dB
- IR 50m
- Alarm 2/1, audio 1/1
- IP67, IK10 housing
- Integrated mounting box
Out of stock
This product is out of stock right now. Leave your e-mail and we will let you know when it is back — or propose an equivalent.
