The BCS-SD15 / 24 adapter is a non-isolated step-down DC / DC converter. The device is powered from the PoE 48 V line and provides a stabilized output voltage of 24 V. The basic application of the adapter is to power WiFi devices that require PoE 24 V. The device can be powered from 802.3af and PoE PASSIVE switches.
BCS POWER
BCS-SD15/24
29,52 € gross
100 In Stock- Non-isolated step-down DC/DC converter
- Powered via 802.3af PoE or PASSIVE PoE
- Input voltage 35–56 VDC, RJ-45 (PoE)
- Output: 24 VDC ±3%, 0.5 A, RJ-45 (PoE)
- The RJ45 output supports LAN communication alongside 24V PoE power supply
- Insulating polyethylene film
- Operating conditions: -10–+40°C
- Dimensions 75x21x17mm
100 in stock
- DPD across Europe & worldwide — free in the EU from 1000,00 € (ex. VAT)
- Official BCS e-commerce Business Partner
- Technical support
| Product | BCS-SD15/24 |
|---|
