A set of converters for transmitting video signal over twisted pair.
BCS UNIVERSAL
BCS-UHD-TR1S (SET)
7,06 € gross
100 In Stock- A set of converters for transmitting video signals over twisted-pair cable
- Real-time transmission
- No power supply required
- Compatible with HDCVI, HDTVI, AHD, CVBS
- Support for NTSC, PAL, SECAM
- Maximum twisted-pair cable length depending on cable quality
- HDCVI 720P: up to 440m, 1080P: up to 250m, 4Mpx: up to 200m, 4K: up to 200m via UTP Cat5e/6
- HDTVI 720P: up to 250m, 1080P: up to 250m, 3Mpx: up to 250m, 4Mpx: up to 180m, 5Mpx: up to 180m, 4K: up to 130m via UTP Cat 5e/6
- AHD 720P: up to 320m, 960H: up to 320m, 1080P: up to 250m, 3Mpx: up to 250m, 4Mpx: up to 200m, 5Mpx: up to 180m, 4K: up to 150m via UTP Cat 5e/6
- CVBS: up to 400m via UTP Cat5e/6
- Male BNC connector with 150mm mini-coax cable
- Screw-on connector for twisted-pair cable
- Built-in transil (TVS) diode providing protection against surges up to 2 kV
- 60 dB resistance to noise and signal interference
- Interference suppression system
100 in stock
- DPD across Europe & worldwide — free in the EU from 1000,00 € (ex. VAT)
- Official BCS e-commerce Business Partner
- Technical support
| Product | BCS-UHD-TR1S (SET) |
|---|
