BCS-V-NVR0802-A-8K-8P
BCS-V-NVR0802-A-8K-8P - Image 2
BCS-V-NVR0802-A-8K-8P - Image 3
BCS-V-NVR0802-A-8K-8P - Image 4
BCS-V-NVR0802-A-8K-8P - Image 5
BCS-V-NVR0802-A-8K-8P - Image 6

BCS-V-NVR0802-A-8K-8P

343,02 € gross

4 In Stock
  • 8-channel IP recorder
  • Built-in 8-port 120W PoE switch
  • Supports 2 hard drives
  • Supports 32Mpx IP cameras
  • HDMI 8K/VGA output
  • Alarm 4/1, audio 1/1

4 in stock

  • DPD across Europe & worldwide — free in the EU from 1000,00 € (ex. VAT)
  • Official BCS e-commerce Business Partner
  • Technical support
SKU: 11298 Categories: , , ,
Product

BCS-V-NVR0802-A-8K-8P
System

IP
Pentaplex function

Live view / recording / playback / archiving / remote access
Channels

8
HDD support

2
HDD capacity

16 TB
Max recording resolution

32 Mpx
Incoming bandwidth

128Mbps
Outgoing bandwidth

256Mbps
Display efficiency

2×32M(30fps) +2×8M(30fps) / 10×8M(30fps) / 8×4M(30fps)
Recording resolutions

(32M/24M)8ch / 12M / 8M / 6M / 5M / 4M / 3M / 2M / UXGA / 720P / VGA / 4CIF / DCIF / 2CIF / CIF / QCIF
Video compression

H.265+ / H265 / H.264+ / H.264
HDMI out

HDMI8K
VGA out

VGA
BNC out

BNC
HDMI display resolutions

7680×4320 / 3840×2160 / 2560×1440 / 1920×1080 / 1600×1200 / 1280×1024 / 1280×720 / 1024×768
VGA display resolutions

1920×1080 / 1600×1200 / 1280×1024 / 1280×720 / 1024×768
Display split

1/4/8
Synchronous playback

1/4/8
Archiving

Possibility to download material to external media such as USB FLASH, USB HDD
User connections

128
Interfaces

1×USB2.0, 1×USB3.0
Audio in

1
Audio out

1
Audio compression

G.711ulaw/G.711alaw/G.722/G.726/AAC/MP2L2
Alarm in

4
Alarm out

1
Support

Local, Web Service, CMS BCS Manager (Windows/Linux/MAC), Mobile App(iOS, android)
Network

RJ-45 10/100/1000Mbps
Compatibility

ONVIF, support third party cameras
Protocols

TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP, HTTP, HTTPS
Standard

IEEE 802.3 af/at
Switch PoE power

120W
PoE channels

8
Power supply

100~240V AC
Power consumption (without HDD)

max 15W
Working environment

-10°C~+55°C max 90% RH
Casing

1U
Dimensions (W×D×H)

385×315×52mm
Weight (without HDD)

3 kg
POS

Yes
Ai - Intelligent functions from camera

SMD, intrusion, crossline, heat map, ARTR, people counting
