| &Ai - Built-in intelligent functions | Yes |
|---|---|
| Power consumption (without HDD) | max 30W |
| Ai - Intelligent functions from recorder | Face detection and face recognition, perimeter protection (human/ vehicle recognition) |
| Ai - Intelligent functions from camera | People counting, ARTR |
| Product | BCS-V-NVR1602-A-4K-Ai(2) |
| System | IP |
| Pentaplex function | Live view / recording / playback / archiving / remote access |
| Channels | 16 |
| HDD support | 2 |
| HDD capacity | 14 TB |
| Max recording resolution | 32 Mpx |
| Incoming bandwidth | 160Mbps |
| Outgoing bandwidth | 256Mbps |
| Display efficiency | 16×2M(30fps) |
| Recording resolutions | 32M(4ch) / 24M(4ch) / 12M / 8M / 6M / 5M / 4M / 3M / 2M / UXGA / 720P / VGA / 4CIF / DCIF / 2CIF / CIF / QCIF |
| Video compression | H.265+ / H265 / H.264+ / H.264 |
| HDMI out | HDMI4K |
| VGA out | VGA |
| BNC out | BNC |
| HDMI display resolutions | 3840×2160 / 1920×1080 / 1600×1200 / 1280×1024 / 1280×720 / 1024×768 |
| VGA display resolutions | 1920×1080 / 1600×1200 / 1280×1024 / 1280×720 / 1024×768 |
| Display split | 1/4/6/8/9/16 |
| Synchronous playback | 1/4/9/16 |
| Archiving | Possibility to download material to external media such as USB FLASH, USB HDD |
| User connections | 128 |
| Interfaces | 1×USB2.0, 1×USB3.0 |
| Audio in | 1 |
| Audio out | 1 |
| Audio compression | G.711ulaw/G.711alaw/G.722/G.726/AAC/MP2L2/PCM |
| Alarm in | 4 |
| Alarm out | 1 |
| Support | Local, Web Service, CMS BCS Manager (Windows/Linux/MAC), Mobile App(iOS, android) |
| Network | 2×RJ-45 10/100/1000Mbps |
| Compatibility | ONVIF, support third party cameras |
| Protocols | TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP, HTTP, HTTPS |
| Power supply | 100~240V AC |
| Working environment | -10°C~+55°C max 90% RH |
| Casing | 1U |
| Dimensions (W×D×H) | 385×315×52mm |
| Weight (without HDD) | 2.5 kg |
| POS | Yes |
| Ai - Perimeter protection | 4 channels 2Mpx, 12 rules |
| &Ai - Object classification | Yes |
| Ai - Face detection | 4 channels 8Mpx |
| Ai - Face recognition | 8 recognition channels, 16 databases, 50k. pictures (max 512KB, total 1GB) |
Warning: This product belongs to the BCS VIEW product line.
Use only components and devices from the same line to ensure compatibility.
BCS VIEW
BCS-V-NVR1602-A-4K-Ai(2)
901,59 € gross
6 In Stock- 16-channel IP recorder
- AcuSense technology
- Supports 2 hard drives
- Supports 32Mpx IP cameras
- HDMI 4K/VGA output
- 4/1 alarm, 1/1 audio
- Built-in smart features
6 in stock
