| Weight (without HDD) | 1.1 kg |
|---|---|
| System | Analog HD + IP |
| Channels | 8 |
| Max recording resolution | 5 Mpx Lite |
| HD-CVI camera | 1080P@30fps 720P@30fps |
| Power consumption (without HDD) | max 8W |
| XVR - IP camera | 4M |
| Product | BCS-B-XVR0801(2.0) |
| Transmission standard | HD-CVI / AHD / HD-TVI / ANALOG / IP |
| Pentaplex function | Live view / recording / playback / archiving / remote access |
| HDD support | 1 |
| HDD capacity | 8 TB |
| Incoming bandwidth | 32Mbps(40Mbps) |
| Outgoing bandwidth | 64Mbps |
| Display efficiency | Analog: 4 x 5MP Lite@6, 4 x 4MP Lite@8, 4 x 1080P Lite @12fps IP: 1 x 4MP@30, 2 x 1080P@30 |
| AHD camera | 5MP@12fps 4MP@15fps 1080P@30fps 720P@30fps |
| HD-TVI camera | 5MP@12fps 4MP@15fps 1080P@30fps 720P@30fps |
| ANALOG camera | CVBS PAL/NTSC |
| XVR - IP channels | 4(8) |
| Recording resolutions | 5MP Lite / 4MP Lite /1080P Lite /720P / CIF |
| Main stream | 5MP Lite@6fps 4MP Lite@8fps 1080P Lite@12fps 720P@12fps |
| Second stream | D1@6fps D1@8fps D1@12fps D1@12fps |
| Video compression | H.265 / H.264 |
| HDMI out | HDMI |
| VGA out | VGA |
| HDMI display resolutions | 1920×1080 / 1600×1200 / 1280×1024 / 1280×720 / 1024×768 |
| VGA display resolutions | 1920×1080 / 1600×1200 / 1280×1024 / 1280×720 / 1024×768 |
| Display split | 1/4/6/8 |
| Synchronous playback | 1/4/8 |
| Archiving | Possibility to download material to external media such as USB FLASH, USB HDD |
| User connections | 128 |
| Interfaces | 2×USB2.0 |
| Audio in | 1 |
| Audio out | 1 |
| Audio compression | G.711U |
| Support | Local, Web Service, CMS BCS Manager (Windows/Linux/MAC), Mobile App(iOS, android) |
| Network | RJ-45(10/100Mbps) |
| Compatibility | ONVIF |
| Protocols | TCP/IP, P2P, UPnP, DHCP, HTTP, HTTPS, DNS, DDNS, SMTP |
| Power supply | 12V DC |
| Working environment | -10°C~+55°C max 90% RH |
| Casing | 1U |
| Dimensions (W×D×H) | 260×243×46mm |
Warning: This product belongs to the BCS BASIC product line.
Use only components and devices from the same line to ensure compatibility.
BCS BASIC
BCS-B-XVR0801(2.0)
88,56 € gross
100 In Stock- 8-channel, 5-system recorder
- HDCVI/AHD/TVI/ANALOGUE/IP
- Supports 1 hard drive
- Supports 5Mpx analogue HD and 4Mpx IP cameras.
- HDMI/VGA output
- Audio 1/1
