8Mpx dome IP camera, BCS Line series, with 1/2.8″ CMOS sensor and 2.7 ~ 13.5mm motozoom lens, WDR (120dB), Infrared illuminator – 40m, 1/1 alarm, 1/1 sound, smart functions, 256 GB microSD memory card slot; IK10, IP67 housing in white colour, power supply: 12V DC. Dimensions: Ø122 x 88.9mm.
Warning: This product belongs to the BCS LINE product line.
Use only components and devices from the same line to ensure compatibility.
BCS LINE
BCS-DMIP3801IR-V-E-Ai
651,90 € gross
Out of Stock- 8Mpx dome IP camera
- 1/2.8" PS CMOS sensor
- 2.7–13.5 mm motorised zoom lens
- WDR 120dB
- Alarm 1/1, audio 1/1
- 40m IR illuminator
- IP67, IK10 housing
Out of stock
This product is out of stock right now. Leave your e-mail and we will let you know when it is back — or propose an equivalent.
| Ai - Human/vehicle detection | Yes |
|---|---|
| Product | BCS-DMIP3801IR-V-E-Ai |
| Camera type | Dome |
| Sensor | 1/2.8'' CMOS |
| RAM | 512MB |
| Aperture | F1.5 |
| Digital zoom | 16× |
| S/N ratio | 56dB |
| Flag | OUTLET |
| Ai - Built-in intelligent functions | Yes |
| Gain control | (AGC) Auto / manual |
| Resolution | 8 Mpx |
| Scanning system | Progressive Scan |
| Pixels | 3840(H)×2160(V) |
| ROM | 128MB |
| Lens | motozoom |
| Focal length | 2.7~13.5 mm |
| Focus | Auto / manual |
| Iris | Auto |
| Optical zoom | 4× |
| Angle of view | H: 113°~31° V: 58°~17° D: 138°~36° |
| DORI | Detect 85~280m / Observe 34~112m / Recognize 17~56m / Identify 9~28m |
| Min illumination | 0.007Lux(F1.5,30IRE) 0.0007Lux(F1.5,B/W,30IRE) 0Lux(IR) |
| White balance | (AWB) Auto / manual |
| WDR | 120dB |
| Backlight compensation | BLC / HLC / WDR(120dB) |
| Shutter | Auto / manual 1/3~1/100000s |
| Noise reduction | 3D DNR |
| Image rotate | Mirror, Flip 0°/90°/180°/270° |
| Stream support | 3 |
| Resolutions | |
| Main stream | 3840×2160(1~20fps(Ai)/1~25/30fps) |
| Second stream | 704×576(1~25fps) 704×480(1~30fps) |
| Third stream | 1920×1080(1~25/30fps) |
| Bitrate | H.264: 3 Kbps~8192 Kbps H.265: 3 Kbps~8192 Kbps |
| Video compression | H.265 / H.265+ / H.264 / H.264+ / MJPEG |
| Day/night | ICR mechanical infrared filter |
| Illuminator type | IR LED |
| IR range | 40m |
| Audio in | 1 |
| Audio out | 1 |
| Audio compression | G.711A / G.711Mu / G.726 |
| Alarm in | 1 |
| Alarm out | 1 |
| Memory card slot | microSD 256GB |
| Support | Web Service, CMS BCS Manager (Windows/Linux/MAC), Mobile App(iOS, android) |
| Motion detect | 4 |
| Privacy masking | 4 |
| Network | RJ-45 10/100 Mbps |
| Compatibility | ONVIF(S/G/T) |
| Protocols | IPv4, IPv6, HTTP, TCP, UDP, ARP, RTP, RTSP, RTCP, RTMP, SMTP, FTP, SFTP, DHCP, DNS, DDNS, QoS, UPnP, NTP, Multicast, ICMP, IGMP, NFS, SAMBA, PPPoE, SNMP |
| Power supply | PoE |
| Power supply type | 12VDC / PoE(802.3af) |
| Power consumption | max 8.2W |
| Housing color | White |
| IP class | IP67 |
| IK10 | Yes |
| Working environment | -30°C~+60°C max 95% RH |
| Dimensions | Ø122×88.9mm |
| Weight | 0.5 kg |
| Ai - Perimeter protection | Yes |
| &Ai - Object classification | Yes |
