Camera 8Mpx HD-CVI / HD-TVI / AHD / ANALOG, sensor 1/2.7″ SONY CMOS with a resolution of 3840 × 2160 (8Mpx), progressive scan, image display: 1080p 2Mpx, Max 25/30 fps @ 1080p, built-in IR radiator – up to 30 meters, built-in microphone, day / night ICR support, D-WDR extended dynamic function, noise reduction, privacy mask, OSD menu support. Graphite-colored casing, protection class: IP67. Power supply: DC 12V. Dimensions: Ø93 x 85.8 mm.
Save 33%
BCS UNIVERSAL
BCS-EA18FWR3-G(2)
56,52 € gross
100 In Stock- 8Mpx analogue HD dome camera
- HDCVI/AHD/TVI/CVBS
- 1/2.7" PS CMOS sensor
- 2.8mm fixed lens
- WDR 120dB
- IR 30m
- Microphone
- IP67 housing
100 in stock
- DPD across Europe & worldwide — free in the EU from 1000,00 € (ex. VAT)
- Official BCS e-commerce Business Partner
- Technical support
| Flag | PROMOTION |
|---|---|
| Product | BCS-EA18FWR3-G(2) |
| Camera type | Dome |
| Transmission standard | HD-CVI / AHD / HD-TVI / ANALOG CVBS |
| Resolution | 8 Mpx |
| Sensor | 1/2.7'' CMOS |
| Scanning system | Progressive Scan |
| Pixels | 3840(H)×2160(V) |
| Lens | fixed |
| Focal length | 2.8 mm |
| Aperture | F2.0 |
| Focus | fixed |
| Iris | fixed |
| Angle of view | H: 106° V: 56° D: 125° |
| DORI | Detect 88m / Observe 35m / Recognize 18m / Identify 9m |
| Min illumination | 0.01Lux(F2.0) 0.001Lux(B/W,F2.0,30IRE) 0Lux(B/W,IR) |
| S/N ratio | 65dB |
| White balance | (AWB) Auto / manual |
| WDR | 120dB |
| Backlight compensation | BLC / HLC / WDR(120dB) |
| Shutter | Auto / manual 1/25(30)s~1/100000s |
| Gain control | (AGC) Auto / manual |
| Noise reduction | 3D DNR |
| Defog | Electronic |
| Image rotate | Mirror |
| Resolutions | CVI: 8M(3840×2160)@15fps 5M(2880×1620)@25fps; 4M(2560×1440)@25fps/30fps; 2M(1920×1080)@25/30fps AHD/TVI: 8M(3840×2160)@15fps CVBS: 960H(960×576/960×480) |
| Day/night | ICR mechanical infrared filter |
| Illuminator type | IR LED |
| IR range | 30m |
| Microphone | Yes |
| Support | Support for settings in the camera OSD menu by the BCS-XVR recorder |
| Privacy masking | 8 |
| Power supply | 12V DC |
| Power supply type | 12V DC |
| Power consumption | max 5W |
| Housing color | Graphite |
| IP class | IP67 |
| Working environment | – 40°~+60° max 95% RH |
| Dimensions | Ø93×85.8mm |
| Weight | 0.5 kg |
