BCS-L-EIP45VSR4-Ai1(2)

442,80 € gross

Out of Stock
  • 5Mpx dome IP camera
  • 1/2.7" PS CMOS sensor
  • SkyLight technology
  • 2.7–13.5 mm motorised zoom lens
  • WDR 120dB
  • IR 40m
  • Microphone
  • IP67-rated housing
  • Built-in smart features

Out of stock

This product is out of stock right now. Leave your e-mail and we will let you know when it is back — or propose an equivalent.

SKU: 11889 Category:
Product

BCS-L-EIP45VSR4-Ai1(2)
Camera type

Dome
Resolution

5 Mpx
Sensor

1/2.7'' CMOS
Scanning system

Progressive Scan
Pixels

2960(H)×1688(V)
RAM

256MB
ROM

128MB
Lens

motozoom
Focal length

2.7~13.5 mm
Aperture

F1.5
Focus

Auto / manual
Iris

Auto
Optical zoom

5×
Digital zoom

16×
Angle of view

H: 113°~31° V: 58°~18° D: 138°~36°
DORI

Detect 64~210m / Observe 26~84m / Recognize 13~42m / Identify 6~21m
Min illumination

0.007Lux(Color,F1.5,30IRE) 0.0007Lux(F1.5,B/W,30IRE) 0Lux(IR)
S/N ratio

56dB
White balance

(AWB) Auto / manual
WDR

120dB
Backlight compensation

BLC / HLC / WDR(120dB)
Shutter

Auto / manual 1/3~1/100000s
Gain control

(AGC) Auto / manual
Noise reduction

3D DNR
Image rotate

Mirror, Flip 0°/90°(corridor mode)/180°/270°
Stream support

2
Resolutions

5M(2960×1668) /4M(2880×1620)(2688×1520)(2560×1440) /3M(2304×1296)(2048×1536) /2M(1920×1080) /720P(1280×720) /D1(704×576/704×480) /VGA(640×480) /CIF(352×288/352×240)
Main stream

2960×1668(1~20fps) 2688×1520(1~25fps)
Second stream

704×576(1~25fps) 704×480(1~30fps)
Bitrate

H.264: 32 Kbps~8192 Kbps H.265: 12 Kbps~8192 Kbps
Video compression

H.265 / H.265+ / H.264 / H.264+ / MJPEG
Day/night

ICR mechanical infrared filter
Illuminator type

IR LED
IR range

40m
Microphone

Yes
Audio compression

G.711A / G.711Mu / G.726 / PCM
Storage

FTP, SFTP, NAS
Memory card slot

microSD 256GB
Support

Web Service, CMS BCS Manager (Windows/Linux/MAC), Mobile App(iOS, android)
Motion detect

4
Privacy masking

4
Network

RJ-45 10/100 Mbps
Compatibility

ONVIF(S/G/T)
Protocols

IPv4, IPv6, HTTP, TCP, UDP, ARP, RTP, RTSP, RTCP, RTMP, SMTP, FTP, SFTP, DHCP, DNS, DDNS, QoS, UPnP, NTP, Multicast, ICMP, IGMP, NFS, PPPoE, Boujour, P2P
&Power supply

PoE
Power supply type

12V DC / PoE(802.3af)
Power consumption

max 7.4W
Housing color

White
IP class

IP67
Working environment

-30°C~+60°C max 95% RH
Dimensions

Ø122×108.3mm
Weight

0.86 kg
Ai - Built-in intelligent functions

Built-in intelligent algorithm of image analisis
Ai - Perimeter protection

Crossline, intrusion
&Ai - Object classification

Yes
&Ai - SMD

Yes
Ai - Human/vehicle detection

Human/vehicle classification for crossline and intrusion reduces false alarms
Ai - SMD - Smart Motion Detection

SMD Plus
